Cisco Webex Room Panorama, Triple Screens, Quad Camera

VENDOR: CISCO Mfg Part#: CS-ROOM-PANO-K9
1 3
Photo is for illustration purposes only. Actual product may be different.
$200,821.61
$200,821.61
Sale Sold out
MSRP: $294,538.38
Shipping calculated at checkout.
  • Triple screen video conferencing solution
  • Quad camera system for immersive video experience
  • TAA compliant for federal and public deployments
  • Manufactured in Mexico
  • Part of Cisco's Webex ecosystem
  • Designed for large collaborative environments

Shipping & Returns

All our products can be shipped anywhere in the Continental United States.

View our shipping and returns policy

View full details

Key Benefits

Eye-Insights
  • TAA compliance makes it suitable for government and regulated industry procurement.
  • Triple screen and quad camera system provide a high-impact, immersive conferencing experience for large rooms.
  • Manufactured by Cisco, ensuring integration with existing enterprise-grade networking infrastructure.

Product Overview

The Cisco Webex Room Panorama, part number CS-ROOM-PANO-K9, is a premium video conferencing solution engineered for large-scale collaboration environments. With a triple screen display and quad camera setup, it offers an immersive and high-fidelity meeting experience. Manufactured in Mexico and compliant with TAA standards, it supports deployment in enterprises and government organizations. Integrated with the Cisco Webex ecosystem, it ensures secure, scalable, and centrally managed conferencing solutions tailored for modern communication challenges.

Specifications

Product Overview
Product Type Video Conferencing System
Form Factor Integrated Room System with Triple Screens and Quad Camera
Weight Approx. 300 kg (system depends on room setup)
Power Requirements 100–240 VAC, 50/60 Hz
Typical Power Consumption 700 W
Maximum Power Consumption 1100 W

Wireless Features
Wi‑Fi Standards Supported 802.11a/b/g/n/ac (Wi-Fi support via Touch Panel)
Bluetooth Bluetooth 4.0 supported (for control devices)
Internal Antennas Yes (Wi-Fi via Touch Panel)

Compliance & Origin
Country of Origin Mexico
TAA Compliance Yes
Certifications CE, FCC Part 15B, UL 60950-1, RoHS, WEEE, RCM, VCCI
Safety Standards IEC 60950-1, EN 60950-1

Advanced Security Features
Encryption Protocols AES-128, AES-256 for media and signaling
Secure Boot and Secure Storage Yes
Admin Authentication Local, LDAP, SAML-based SSO integration
Media Encryption SRTP (Secure Real-time Transport Protocol)
Firewall and NAT Traversal Cisco Expressway or VCS supported

Interfaces
HDMI Inputs 4
HDMI Outputs 3 (for triple screens)
LAN Ports 1 x 10/100/1000 Ethernet (RJ-45) for network connection
USB Ports 2 x USB 3.0, 1 x USB-C
Audio Line In 3 (Balanced Line-In, 3.5 mm jack and USB)
Audio Line Out 2 (Balanced Line-Out)
Control Interfaces 1 x RJ45 for Touch 10 / Touch Panel control connection
Video Output Resolution 1920 x 1080 @ 60 fps
Camera Output Quad 5K Ultra HD (4096 x 2160)

Physical & Environmental
Main Unit Dimensions 355 mm x 970 mm x 180 mm
Screen Size (each) 82" LCD Display Panels
Operating Temperature 0°C to 35°C (32°F to 95°F)
Storage Temperature -20°C to 60°C (-4°F to 140°F)
Relative Humidity 10% to 90% (non-condensing)
Noise Levels < 40 dBA (typical)

Cloud Management & Licensing
Cloud Management Platform Cisco Webex Control Hub
Management Interface Web GUI, SSH, Cisco Webex API
Licensing Model Cisco Smart Licensing
Webex RoomOS Support Yes
Included Cloud Features Device registration, software updates, status monitoring
