HP Aruba CX 8360 v2 Switch, 48-Port, MACsec, 110W, R9G12A#ABA

VENDOR: HP Mfg Part#: R9G12A#ABA UPC#: 190017597522
1 1
Photo is for illustration purposes only. Actual product may be different.
$28,350.51
$28,350.51
Sale Sold out
MSRP: $37,125.00
Shipping calculated at checkout.
  • 1. 1.8 GHz 4-core 64-bit processor with 16 GB RAM and 32 GB Flash for high-capacity routing.
  • 2. Layer 3 Advanced routing with MACsec secure connectivity for encrypted data transmission.
  • 3. 48 ports of 100M/1GbE/10GBASE-T and 4 ports of 40GbE/100GbE via QSFP+/QSFP28.
  • 4. 110 Watt maximum power consumption for energy-efficient operation.
  • 5. TAA-compliant and localized for US English markets.
  • 6. Backed by HP's Limited Lifetime Warranty for long-term support.

Shipping & Returns

All our products can be shipped anywhere in the Continental United States.

View our shipping and returns policy

View full details

Key Benefits

Eye-Insights
  • Delivers high-throughput, secure Layer 3 switching with MACsec, ideal for enterprise-grade deployments.
  • Offers extensive port flexibility, including support for QSFP+/QSFP28 and breakout cables to adapt to varied network demands.
  • Includes HP's Limited Lifetime Warranty, ensuring superior long-term value and reduced total cost of ownership.

Product Overview

The HP Aruba CX 8360 v2 Switch (R9G12A#ABA) is a Layer 3 managed switch crafted for modern enterprise and data center use. Featuring a 1.8 GHz 4-core CPU, 16 GB RAM, and 32 GB of storage, it provides robust resources to support extensive routing protocols. The switch is equipped with a 32 MB packet buffer, and includes integrated MACsec encryption to ensure secure data transport even over untrusted domains. This model supports up to 48 10GBASE-T and 4 QSFP+/QSFP28 ports, with flexible breakout cable options enhancing deployment versatility. Consuming only 110 Watts, the unit remains efficient while delivering enterprise-grade performance. TAA compliance and a limited lifetime warranty ensure suitability in federal and large-scale IT environments.

Specifications

Product Overview
Product Type Layer 3 Managed Switch
Model Aruba CX 8360 v2 Switch Series
Part Number R9G12A#ABA
Form Factor 1U Rackmount
Processor 1.8 GHz Quad-Core ARM CPU
System Memory (RAM) 16 GB
Internal Storage 32 GB eMMC
Packet Buffer Size 32 MB
Power Consumption (Typical) 110 Watts
Max Power Consumption 110 Watts
Weight 23.65 lbs.

Wireless Features
Wireless Capabilities

Compliance & Origin
Country of Origin Singapore
TAA Compliant Yes
Certifications UL, cUL, CB, FCC, VCCI, CE, BSMI
RoHS Compliance Yes
Warranty Limited Lifetime Warranty

Advanced Security Features
MACsec Encryption Yes, IEEE 802.1AE
Access Control 802.1X, MAC authentication, web-based authentication
Policy-Based Routing Yes
Dynamic Segmentation Supported with ClearPass integration
Security Protocol Support SSH, SNMPv3, RADIUS, TACACS+

Interfaces
10GBASE-T Ports 48
QSFP+/QSFP28 Ports 4
Total Number of Ports 52
Interface Type 10GBASE-T and QSFP+/QSFP28
Breakout Cable Support Yes, 4x10G/25G breakout
MACsec Encryption Yes
Port Speed 100M/1G/10G/25G/40G/100G Depending on Port Configuration
Switching Capacity Up to 2.6 Tbps (model dependent)
Throughput Up to 1935 Mpps

Physical & Environmental
Dimensions (H x W x D) 1.72 x 17.45 x 18 in (4.37 x 44.3 x 45.72 cm)
Mounting Type Rack-mountable
Operating Temperature 32°F to 131°F (0°C to 55°C)
Storage Temperature -40°F to 158°F (-40°C to 70°C)
Operating Humidity 5% to 95% (non-condensing)
Noise Level 45.9 dB (typical)
Cooling Type Front-to-back airflow with fan tray

Cloud Management & Licensing
Management Interface ArubaOS-CX CLI, GUI, REST API, NetEdit, AirWave, Aruba Central
Licensing Model Aruba Central or on-prem via AirWave or NetEdit (subscription required)
Cloud Managed Yes, via Aruba Central
