HP Elite Mini 800 G9, i5-14500T, 16GB DDR5, 256GB SSD, Win 11 Pro

VENDOR: HP Mfg Part#: A12GLUT#ABA UPC#: 198122694617
1 3
Photo is for illustration purposes only. Actual product may be different.
$1,269.00
$1,269.00
Sale Sold out
Shipping calculated at checkout.
  • Intel Core i5-14500T processor (14-core, 1.7GHz base, 4.8GHz Max Turbo, 24MB Smart Cache)
  • 16GB DDR5 SODIMM RAM at 4800MHz
  • 256GB PCIe NVMe M.2 SSD for fast storage
  • Intel UHD Graphics 770 with HDMI 2.1 and DisplayPort 1.4
  • Integrated Intel Wi-Fi 6E AX211, Bluetooth 5.3, and Gigabit Ethernet
  • Mini form factor (6.97" x 6.89" x 1.35"), 90W power supply, 89% efficient

Shipping & Returns

All our products can be shipped anywhere in the Continental United States.

View our shipping and returns policy

View full details

Key Benefits

Eye-Insights
  • Optimized for professional use with powerful 14-core Intel i5-14500T and vPro Enterprise platform
  • Compact footprint and high connectivity with Wi-Fi 6E, HDMI 2.1, and multiple M.2 expansion slots
  • Comes preloaded with Windows 11 Pro, keyboard, and mouse for easy deployment out-of-the-box

Product Overview

The HP Elite Mini 800 G9 is engineered to deliver powerhouse performance in a compact mini-PC design, ideal for professional workstations where space is at a premium. This system is powered by a 14-core Intel Core i5-14500T processor with a base clock of 1.7GHz and a Max Turbo frequency of 4.8GHz, backed by Intel’s 14th generation vPro Enterprise platform. With 16GB of DDR5 SODIMM RAM at 4800MHz and a 256GB PCIe NVMe M.2 SSD, it handles demanding multitasking and fast data access with ease. The integrated Intel UHD Graphics 770 supports modern display outputs via HDMI 2.1 and DisplayPort 1.4 for multi-monitor setups.

Connectivity and expandability are strong points, featuring Intel Wi-Fi 6E AX211, Bluetooth 5.3, and Gigabit Ethernet. Additional professional-grade features include TPM 2.0, HP TamperLock, and three M.2 expansion slots. The mini form factor (just 6.97 x 6.89 x 1.35 inches, 3.13 lbs.) is paired with a 90W power supply offering 89% energy efficiency. It includes a wired USB keyboard and mouse, plus Microsoft Windows 11 Pro for a ready-to-deploy configuration. This system carries a standard 1/1/1 warranty, with options to extend to onsite service.

Specifications

Product Overview
Product Type Mini Desktop PC
Model HP Elite Mini 800 G9
Processor Intel Core i5-14500T, 14-Core, 1.7 GHz (max 4.8 GHz), 24MB Smart Cache
Chipset Intel Q670
RAM 16 GB DDR5 4800 MHz SODIMM
Memory Slots 2 SODIMM slots
Maximum RAM Supported 64 GB
Storage 256 GB PCIe NVMe M.2 SSD
Graphics Intel UHD Graphics 770
Audio Realtek ALC3252 codec, universal audio jack with CTIA and OMTP support
Speakers Yes
Input Devices Wired USB Keyboard (Standard 320K), USB Mouse
Operating System Windows 11 Pro 64-bit
Form Factor Mini
Power Supply 90W External, 89% Efficiency
Weight 3.13 lbs

Wireless Features
Wi-Fi Intel Wi-Fi 6E AX211 (802.11ax)
Bluetooth Bluetooth 5.3
Wireless Antenna External Antenna Supported

Compliance & Origin
Country of Origin Mexico
TAA Compliant Yes
Certifications ENERGY STAR, EPEAT Gold, FCC, UL, RoHS

Advanced Security Features
Trusted Platform Module (TPM) TPM 2.0
Physical Security HP TamperLock
Other Security Features HP Sure Click, HP Sure Start Gen6

Interfaces
Display Outputs 2 x DisplayPort 1.4, 1 x HDMI 2.1
USB Ports 3 x USB 3.2 Gen 2 Type-A (10 Gbps)
Ethernet 1 x RJ-45 (Gigabit Ethernet)
Audio Jack 1 x Universal Audio Jack (CTIA & OMTP support)
Antenna Connector 1 x External Antenna Connector
Expansion Bays 1 x 2.5" internal bay (free)
Expansion Slots 1 x M.2 2230, 2 x M.2 2280

Physical & Environmental
Dimensions (W x D x H) 6.97 x 6.89 x 1.35 in
Operating Temperature Range 10°C to 35°C (50°F to 95°F)
Storage Temperature Range -30°C to 60°C (-22°F to 140°F)
Operating Humidity Range 10% to 90% (non-condensing)
Storage Humidity Range 5% to 95% (non-condensing)

Cloud Management & Licensing
Platform Technology Intel vPro Enterprise
Management Features HP Manageability Integration Kit, HP BIOSphere Gen6, HP Sure Admin
Warranty 1-year parts, labor, and on-site service (1/1/1)
