PLANAR HRO-1.5 Outdoor LED Display Cabinet, 1.5mm Pixel Pitch

VENDOR: PLANAR Mfg Part#: 998-2532-00
  • PLANAR
1 1
Photo is for illustration purposes only. Actual product may be different.
$3,428.85
$3,428.85
Sale Sold out
MSRP: $3,450.00
Shipping calculated at checkout.
  • - LED display cabinet designed for outdoor use
  • - 1.5mm pixel pitch for high definition image fidelity
  • - 7000:1 contrast ratio for vibrant color and deep blacks
  • - 21.7-inch diagonal size offers a compact display surface
  • - Cabinet dimensions: 480mm (W) x 270mm (H) x 50mm (D)

Shipping & Returns

All our products can be shipped anywhere in the Continental United States.

View our shipping and returns policy

View full details

Key Benefits

Eye-Insights
  • - Fine pixel pitch of 1.5mm ensures high image resolution even for close-up viewing in outdoor settings
  • - Compact dimensions simplify installation in space-limited environments or integrated display walls
  • - Excellent 7000:1 contrast ratio provides clear visibility in varied ambient lighting conditions

Product Overview

HRO Outdoor Series LED Display Cabinet. 480 x 270 x 50mm cabinet. 1.5mm pitch

Specifications

Product Overview
Product Type Outdoor LED Display Cabinet
Series HRO Outdoor Series
Pixel Pitch 1.5 mm
Display Size (Diagonal) 21.7 inch
Cabinet Dimensions (W x H x D) 480 x 270 x 50 mm
Cabinet Width 480 mm
Cabinet Height 270 mm
Cabinet Depth 50 mm
Contrast Ratio 7000:1
Cabinet Material Aluminum Alloy
Display Brightness Up to 6000 nits
Viewing Angle (H/V) 160° / 140°
Power Consumption (Typical) 230 W per cabinet
Power Consumption (Max) 690 W per cabinet
Input Voltage Range 100–240V AC, 50/60Hz
Service Access Front and Rear

Wireless Features
Wireless Control Support Optional via wireless access point

Compliance & Origin
Country of Origin
TAA Compliant
Certifications CE, FCC Class A, ETL
RoHS Compliance Yes

Advanced Security Features
Access Control Password-protected management access
Firmware Security Encrypted firmware updates via controller

Interfaces
Video Input HDMI, DVI, DisplayPort via controller
Data Connectivity Ethernet-based (via controller)
Control Interface RJ45 (Ethernet), USB

Physical & Environmental
IP Rating (Front/Rear) IP65 / IP54
Operating Temperature -20°C to +50°C (-4°F to +122°F)
Storage Temperature -40°C to +60°C (-40°F to +140°F)
Operating Humidity 10% to 90% RH (non-condensing)
Installation Type Wall mount, stackable, hanging
Cabinet Weight Approximately 6.5 kg
LED Lifetime ≥100,000 hours
Module Resolution 320 x 180 pixels
Heat Dissipation Method Fanless design with passive cooling

Cloud Management & Licensing
Remote Management Supported via controller software
Control Software Planar WallDirector Video Controller required
Configuration Interface Web-based GUI via controller
