Products Memory, Storage and Components StarTech 2-Port DisplayPort...

StarTech 2-Port DisplayPort KVM Switch, 8K 60Hz / 4K 144Hz, DP 1.4, USB

VENDOR: STARTECH Mfg Part#: D86A2-2-PORT-8K-KVM UPC#: 065030894906
1 5
Photo is for illustration purposes only. Actual product may be different.
$402.99
$402.99
Sale Sold out
Shipping calculated at checkout.
  • - Supports 8K at 60Hz and 4K at 144Hz via DisplayPort 1.4 (DSC required)
  • - 2 USB 3.0 ports with 5Gbps bandwidth for fast data transfer
  • - 4 USB 2.0 HID ports for keyboard and mouse sharing
  • - Hotkey and push-button switching options
  • - OS-independent for flexible system compatibility
  • - TAA compliant and metal housing for government or enterprise use

Shipping & Returns

All our products can be shipped anywhere in the Continental United States.

View our shipping and returns policy

View full details

Key Benefits

Eye-Insights
  • - Enables ultra-high resolution output with 8K/60Hz and 4K/144Hz, ideal for visually intensive professional workflows
  • - Provides versatile connectivity with high-speed USB 3.0 and HID support, streamlining multi-system setups
  • - TAA compliance and durable metal construction make it suitable for regulated deployments and demanding environments

Product Overview

2-Port KVM enables fast switching between USB-A/DisplayPort-enabled desktops sharing keyboard/mouse and an 8K 60Hz monitor; DSC support required for maximum performance; Universal KVM is OS independent; Push-button or hotkey switching; Metal housing

Specifications

Product Overview
Product Type 2-Port DisplayPort KVM Switch
Form Factor Desktop
Enclosure Type Metal Housing
Number of Ports 2
Max Supported Resolution 7680 x 4320 (8K) at 60Hz / 3840 x 2160 (4K) at 144Hz
Display Technology DisplayPort 1.4 with DSC (Display Stream Compression)
Power Requirements USB powered or external power supply (not included)
OS Compatibility OS Independent (Windows, macOS, Linux, ChromeOS)

Physical & Environmental
Dimensions 161 mm x 72 mm x 27 mm
Weight 0.55 kg (1.2 lbs)
Operating Temperature 0°C to 40°C (32°F to 104°F)
Storage Temperature -20°C to 60°C (-4°F to 140°F)
Operating Humidity 10% to 80% RH, non-condensing
Storage Humidity 5% to 95% RH, non-condensing
Color Black

Cloud Management & Licensing
Remote Management Interface No
Cloud Management Not Supported
Licensing Requirements None

Interfaces
Video Input Ports 2 x DisplayPort 1.4
Video Output Ports 1 x DisplayPort 1.4
USB Hub Ports 2 x USB 3.2 Gen 1 Type-A (5Gbps)
Dedicated HID Ports 4 x USB 2.0 Type-A
Console USB Ports 2 x USB Type-A (Keyboard/Mouse)
KVM Switching Method Push-Button or Hotkey
Audio Support No
DisplayPort Version 1.4
USB Data Transfer Rate 5 Gbps on USB 3.2 Gen 1 ports

Compliance & Origin
Country of Origin Taiwan
TAA Compliant Yes
RoHS Compliance Yes
CE Certification Yes
FCC Certification Yes
REACH Compliance Yes
WEEE Compliance Yes

Advanced Security Features
Keyboard/Mouse Emulation Yes
Hotkey Command Security Yes
Physical Port Disable Feature No
