STARTECH 6-Port SATA III PCIe x4 Controller Card - 6Gbps

VENDOR: STARTECH Mfg Part#: 6P6G-PCIE-SATA-CARD UPC#: 065030893749
1 5
Photo is for illustration purposes only. Actual product may be different.
$70.83
$70.83
Sale Sold out
MSRP: $75.99
Shipping calculated at checkout.
  • Adds six SATA III 6Gbps ports via PCIe x4 interface
  • Supports both HDDs and SSDs for improved storage flexibility
  • Delivers high-speed 6Gbps data transfer rate
  • Compact size: 2.1 x 3.2 x 0.7 inches for small form factor installations
  • TAA compliant and backed by a 2-year warranty

Shipping & Returns

All our products can be shipped anywhere in the Continental United States.

View our shipping and returns policy

View full details

Key Benefits

Eye-Insights
  • Offers scalable storage upgrade by adding six SATA ports to desktops or servers
  • Provides high-speed 6Gbps performance ideal for data-intensive applications
  • TAA compliance ensures suitability for government and regulated industry use

Product Overview

Solid State Drive,Hard Drive - PCI Express x4 - 6Gbps - Add six SATA III 6Gbps ports to your desktop computer or server using a PCIe x4 slot to connect SATA drives (HDD/SSD); 6-Port SATA PCIe card features 6x SATA connections for connecting drives using SATA cables (sold separately)

Specifications

Product Overview
Product Type SATA Controller Card
Form Factor Plug-in card
Connector Type PCI Express x4
Number of SATA Ports 6
Drive Support HDD, SSD
RAID Support No
Hot Swap Support Yes
Power Requirements Powered via PCI Express slot

Physical & Environmental
Width 2.1 in (53 mm)
Depth 3.2 in (82 mm)
Height 0.7 in (18 mm)
Product Weight 0.1 lb (40 g)
Operating Temperature 5°C to 50°C (41°F to 122°F)
Storage Temperature -25°C to 70°C (-13°F to 158°F)
Operating Humidity 20% - 80% RH
Storage Humidity 15% - 90% RH

Cloud Management & Licensing
Management Interface
Licensing Required No
Bundled Software Standard device drivers (OS dependent)

Additional Information
Manufacturer StarTech
Manufacturer Part Number 6P6G-PCIE-SATA-CARD
UPC 065030893749
Warranty 2 Years

Interfaces
Host Interface PCI Express 2.0 x4
Device Interface SATA III (6 Gbps)
Data Transfer Rate Up to 6 Gbps per port
Ports 6 x SATA III
Connector Types 6 x 7-pin SATA

Compliance & Origin
Country of Origin Taiwan
TAA Compliant Yes
Certifications CE, FCC, RoHS
Environmental Standards RoHS Compliant

Advanced Security Features
Hardware Encryption No
Secure Boot Support No
Content Filtering No
