StarTech M.2 PCIe NVMe & SATA SSD USB 3.1 Gen 2 Enclosure

VENDOR: STARTECH Mfg Part#: SM2E1BMU31C UPC#: 065030891684
1 5
Photo is for illustration purposes only. Actual product may be different.
$76.68
$76.68
Sale Sold out
MSRP: $82.99
Shipping calculated at checkout.
  • Supports both PCIe NVMe (M-Key) and SATA AHCI (B+M Key) M.2 SSDs
  • Compatible with M.2 form factors: 2230, 2242, 2260, and 2280
  • USB 3.1 Gen 2 interface with 10Gbps data transfer speed
  • Includes both USB-C and USB-A cables for broad host compatibility
  • Durable vented black aluminum enclosure for optimal heat dissipation
  • Backed by a 2-year manufacturer warranty and TAA compliant

Shipping & Returns

All our products can be shipped anywhere in the Continental United States.

View our shipping and returns policy

View full details

Key Benefits

Eye-Insights
  • Supports both PCIe and SATA M.2 SSDs, maximizing compatibility and reducing the need for multiple enclosures
  • USB 3.1 Gen 2 interface delivers high-speed 10Gbps transfers, ideal for large file operations and backups
  • TAA compliance and 2-year warranty enhance its value for government and enterprise procurement

Product Overview

External USB/USB Type-C to SATA M.2 or PCIe M.2 NVMe SSD Enclosure - Works w/ PCIe (M Key) M.2 NVMe and SATA AHCI (B+M-Key) M.2 SSDs (2230/2242/2260/2280) - USB 3.1 Gen 2 10Gbps; PCI Express 3.0 - USB-C + USB-A host cables - Vented aluminum case

Specifications

Product Overview
Product Type M.2 SSD Enclosure
Enclosure Type External
Form Factor M.2 2230/2242/2260/2280
Material Aluminum
Cooling Method Passive (vented aluminum case)
Power Source Bus-powered via USB
Color Black
Warranty 2 Years

Wireless Features
Wireless Capability

Compliance & Origin
TAA Compliant Yes
Country of Origin Taiwan
Certifications CE, FCC, RoHS

Advanced Security Features
Hardware Encryption No
Security Lock Slot No
Drive Protection No integrated encryption or authentication

Interfaces
Host Interface USB 3.1 Gen 2 Type-C
Additional Host Interface USB 3.1 Gen 2 Type-A
Maximum Data Transfer Rate 10 Gbps
Drive Interface M.2 SATA & M.2 NVMe PCIe
Drive Form Factors Supported 2230, 2242, 2260, 2280 M.2
M-Key Support Yes (PCIe NVMe SSDs)
B+M Key Support Yes (SATA SSDs)
PCI Express Version PCIe 3.0
UASP Support Yes
TRIM Support Yes

Physical & Environmental
Width 130 mm (5.1 in)
Depth 40 mm (1.6 in)
Height 15 mm (0.6 in)
Weight 96 g (3.4 oz)
Operating Temperature 0°C to 40°C (32°F to 104°F)
Storage Temperature -10°C to 65°C (14°F to 149°F)
Humidity 10% ~ 90% RH (non-condensing)

Cloud Management & Licensing
Managed Through Cloud
Software Included No software required
