StarTech 3-Port 4K HDBaseT HDMI Extender Over CAT5/CAT6 - ST124HDBT

VENDOR: STARTECH Mfg Part#: ST124HDBT UPC#: 065030864558
1 5
Photo is for illustration purposes only. Actual product may be different.
$1,408.00
$1,408.00
Sale Sold out
Shipping calculated at checkout.
  • Supports 4K resolution (4096 x 2160 @ 30Hz) up to 35m distance
  • Max transmission distance of up to 70 meters over CAT5e or better
  • Three-port HDMI output for 1x3 HDBaseT distribution
  • Wired Ethernet connectivity with Cat 5e UTP or higher cabling
  • Mountable black enclosure with dimensions 5.7" x 7.9" x 1.2"
  • Includes 2-year manufacturer support; TAA-compliant for government use

Shipping & Returns

All our products can be shipped anywhere in the Continental United States.

View our shipping and return policy

View full details

Key Benefits

Eye-Insights
  • Ideal for digital signage and multi-display AV setups requiring up to three 4K UHD outputs
  • Leverages existing Ethernet infrastructure (Cat 5e or better), reducing cabling costs and installation complexity
  • TAA compliance and reliable 2-year support make it suitable for government and enterprise deployments

Product Overview

Distribute your HDMI source to three remote displays over standard CAT5 CAT6 or CAT7 cable - HDMI splitter - 4K digital signage distribution - HDMI extender - HDBaseT extender - 1x3 HDMI extender - Mountable HDMI over CAT6 extender - HDBaseT splitter

Specifications

Product Overview
Product Type HDBaseT HDMI Extender and Splitter
Form Factor External Box
Enclosure Color Black
Power Requirements 12V DC, 3A
Weight 0.64 kg
Mounting Type Wall or Shelf Mountable
Included Accessories Power adapter, mounting brackets
Warranty 2 Years

Wireless Features
Wi-Fi Support

Compliance & Origin
Country of Origin Taiwan
TAA Compliant Yes
Certifications CE, FCC, RoHS

Advanced Security Features
Content Protection HDCP 1.4
Signal Encryption No encryption

Interfaces
Video Input Ports 1 x HDMI
Video Output Ports 3 x RJ-45 (HDBaseT)
HDMI Version HDMI 1.4
HDCP Support Yes
EDID Management Yes
Interface Type HDBaseT over Cat5e/6/7
Maximum Data Rate 10.2 Gbps

Physical & Environmental
Width 5.7 inch (145 mm)
Depth 7.9 inch (200 mm)
Height 1.2 inch (30 mm)
Operating Temperature 0°C to 40°C (32°F to 104°F)
Storage Temperature -10°C to 60°C (14°F to 140°F)
Operating Humidity 10% to 85% RH, non-condensing
Storage Humidity 5% to 90% RH, non-condensing
Housing Material Aluminum

Cloud Management & Licensing
Cloud Management
Licensing Requirements None

Additional Features
Splitter Functionality 1x3 HDMI over HDBaseT Splitter
Distance - 4K Resolution Up to 35 m (115 ft)
Distance - 1080p Resolution Up to 70 m (230 ft)
Supported Resolutions 4K @30Hz, 1080p @60Hz
Cable Type Required Cat5e or better (UTP/STP)
Plug-and-Play Yes
Audio Support Yes - Dolby TrueHD, DTS-HD Master Audio
LED Indicators Power, Link/Activity
