StarTech 4-Slot PCIe Expansion Chassis, PCIe 2.0 x1 Adapter

VENDOR: STARTECH Mfg Part#: 4PCIE-PCIE-ENCLOSURE UPC#: 065030894630
1 5
Photo is for illustration purposes only. Actual product may be different.
$697.00
$697.00
Sale Sold out
Shipping calculated at checkout.
  • 4-slot PCIe 2.0 expansion chassis supporting PCIe x1 cards
  • Delivers up to 10Gbps throughput via PCIe 2.0 x2 host connection
  • Includes 6ft (1.8m) USB-C locking cable for stable connectivity
  • Built with SECC steel enclosure that tolerates up to 140°F
  • TAA compliant for government and regulatory usage
  • Made in Taiwan, ensuring high manufacturing quality

Shipping & Returns

All our products can be shipped anywhere in the Continental United States.

View our shipping and return policy

View full details

Key Benefits

Eye-Insights
  • Enables scalable PCIe expansion without altering internal system design, supporting rapid deployment
  • Ideal for adding multiple I/O interface cards (USB, Ethernet/fiber, serial) in workstations or servers
  • Durable steel construction and TAA compliance align with enterprise and government procurement standards

Product Overview

4-Slot PCIe Expansion Chassis External PCIe Slots for Desktop/Server Host Card PCI-e 2.0 x2, 10Gbps, included 6ft (1.8m) USB-C locking cable For USB, Ethernet/fiber, or Serial/I-O cards SECC steel enclosure withstands temps up to 140 degrees fahre

Specifications

Product Overview
Product Type Chassis
Form Factor External Expansion Chassis
Number of PCIe Slots 4
Enclosure Material SECC Steel
PCI Express Version PCIe 2.0
Card Type Compatibility Full-length, full-height PCIe cards
Included Cable Length 1.8 m (6 ft)
Cable Type USB-C locking cable
Throughput Up to 10 Gbps
Power Input External Power Adapter (Included)
Max Operating Temperature 60°C (140°F)
Cooling Integrated Fan
MTBF 150,000 hours

Wireless Features
Wi‑Fi Support

Compliance & Origin
Country of Origin Taiwan
TAA Compliance Yes
RoHS Compliance Yes
CE Certified Yes
FCC Compliance Yes
REACH Compliant Yes

Advanced Security Features
Integrated Security Features

Interfaces
Host Interface PCIe x1 via included adapter card
Expansion Interface PCIe x8 slot (operates at x4 speed)
Expansion Slots 4 x PCI Express slots
Ports Included 1 x USB-C (on enclosure for host connection)
Cable Interface USB 3.1 Gen 2 Type-C
Data Transfer Rate Up to 10 Gbps via USB-C connection

Physical & Environmental
Enclosure Type Steel
Color Black
Product Dimensions 312 mm x 172 mm x 91 mm
Product Weight 2.5 kg
Operating Temperature 5°C to 60°C (41°F to 140°F)
Storage Temperature -20°C to 70°C (-4°F to 158°F)
Operating Humidity 20% to 80% RH (non-condensing)
Storage Humidity 10% to 90% RH (non-condensing)
