STARTECH Extender Kit HDMI Over IP - 4K, 100M Range, TAA-Compliant

VENDOR: STARTECH Mfg Part#: ST12MHDLAN4K UPC#: 065030868372
1 5
Photo is for illustration purposes only. Actual product may be different.
$896.00
$896.00
Sale Sold out
Shipping calculated at checkout.
  • Supports HDMI over IP with resolution up to 4K @ 30Hz
  • Transmits signals over Cat 5e UTP or better cabling
  • Maximum transmission distance of 100 meters
  • TAA-compliant for government and regulated environments
  • Ethernet-based (wired) connectivity using standard networking protocols
  • Compact design with dimensions: 4.6" W x 5.1" D x 1.2" H

Shipping & Returns

All our products can be shipped anywhere in the Continental United States.

View our shipping and return policy

View full details

Key Benefits

Eye-Insights
  • Delivers high-definition 4K video at 30Hz over IP, ideal for professional AV installations
  • Up to 100m transmission range using industry-standard Cat 5e or better cables simplifies infrastructure
  • TAA compliance ensures suitability for government and regulatory applications

Product Overview

Deploy HDMI over LAN and get a video over IP solution thats scalable and features intuitive control thats ideal for your video wall or other digital signage application - 4K30 - AV over IP - HDMI over IP network - HDMI over LAN - Video over IP

Specifications

Product Overview
Product Type HDMI Over IP Extender Kit
Manufacturer StarTech
Manufacturer Part Number ST12MHDLAN4K
UPC 065030868372
Video Output Resolutions Up to 3840 x 2160 (4K @ 30Hz)
Maximum Transmission Distance 100 m (328 ft)
Form Factor Standalone unit
Power Adapter Included Yes
Power Input 100-240V AC, 50/60Hz
Device Type Video Extender
Connectivity Technology Wired
Enclosure Color Black
Service & Support Type 2 Years

Wireless Features
Wireless Capability

Compliance & Origin
Country of Origin Taiwan
TAA Compliant Yes
Certifications CE, FCC, RoHS
Compliance Standards HDCP 1.4

Advanced Security Features
Content Protection HDCP 1.4 compliant
Authentication MAC address filtering
Password Protection Yes

Interfaces
Input Interface 1 x HDMI (Type A)
Output Interface 1 x HDMI (Type A)
Network Interface 1 x RJ-45 (Gigabit Ethernet)
IR Interface 1 x IR Receiver, 1 x IR Blaster
Serial Interface 1 x RS-232 (3-pin terminal block)
Supported Cabling Type Cat 5e/6 UTP or better
Supported Network Protocols TCP/IP, UDP, IGMP

Physical & Environmental
Width 4.6 in (117 mm)
Depth 5.1 in (130 mm)
Height 1.2 in (30 mm)
Weight 0.7 lb (0.3 kg)
Operating Temperature 0°C to 40°C (32°F to 104°F)
Storage Temperature -10°C to 60°C (14°F to 140°F)
Humidity Range 10% to 85% RH (non-condensing)

Cloud Management & Licensing
Management Interface Web Browser Interface
Centralized Control Yes, via Web GUI or optional software
Licensing Requirements No additional licensing required
