StarTech Industrial 8 Port Gigabit PoE Switch, 30W, -40°C to +75°C

VENDOR: STARTECH Mfg Part#: IES81GPOEW UPC#: 065030871112
1 5
Photo is for illustration purposes only. Actual product may be different.
$428.00
$428.00
Sale Sold out
MSRP: $430.00
Shipping calculated at checkout.
  • 8-port Gigabit Ethernet switch with 10/100/1000 Mbps auto-negotiation
  • Supports Power over Ethernet up to 30W on four ports
  • Wide operating temperature range: -40°C to +75°C
  • IP-30 rated rugged enclosure with shock and vibration resistance
  • 6kV ESD protection and MTBF rated over 500,000 hours
  • DIN-rail and wall mounting options for flexible installation

Shipping & Returns

All our products can be shipped anywhere in the Continental United States.

View our shipping and return policy

View full details

Key Benefits

Eye-Insights
  • Engineered for industrial environments with a wide -40°C to +75°C temperature range and IP-30 housing
  • Provides reliable PoE support up to 30W on 4 ports, ideal for powering edge devices like IP cameras
  • Offers long-term dependability with 6kV ESD protection and over 500,000 hours MTBF

Product Overview

Industrial 8 port Gigabit PoE switch Up to 30W per 4 Power over Ethernet ports +75C to -40C temp 10/100/1000 Mbps network auto IP-30 housing MTBF 500000+hrs - Vibration/shock/free fall rated - 6kV ESD Full layer/L2 managed DIN/wall mounting 2 yr warr

Specifications

Product Overview
Type Industrial 8-Port Gigabit PoE Ethernet Switch
Form Factor DIN Rail or Wall Mountable
Weight 22.9 oz (650 g)
Power Consumption Max 120W (PoE devices included)
Power Input 48 ~ 56V DC
MTBF 500,000+ hours
PoE Budget 30W per port (Ports 1-4)
Network Device Type Switch
Layer Support Layer 2
Warranty 2 Years

Physical & Environmental
Dimensions (W x D x H) 5.8 x 5.3 x 1 in (147 x 135 x 26 mm)
Operating Temperature -40°C to 75°C
Storage Temperature -40°C to 90°C
Operating Humidity 5% to 95% RH Non-condensing
Housing Material Rugged IP-30 rated metal enclosure
Installation Options DIN Rail and Wall Mountable
Vibration Resistance IEC 60068-2-6
Shock Resistance IEC 60068-2-27
Free Fall Resistance IEC 60068-2-32

Cloud Management & Licensing
Management Unmanaged
Remote Monitoring No

Interfaces
Number of Ethernet Ports 8 x 10/100/1000 Mbps Gigabit
PoE Ports 4 x RJ-45 with IEEE 802.3af/at support
Non-PoE Ports 4 x RJ-45
Network Protocols Supported IEEE 802.3, 802.3u, 802.3ab, 802.3x flow control
MAC Address Table Size 4K entries
Switching Capacity 16 Gbps
Forwarding Rate 11.9 Mpps
Jumbo Frame Support Yes, up to 9KB
Auto MDI/MDI-X Yes
Auto-Negotiation Yes

Compliance & Origin
Country of Origin Taiwan
TAA Compliant Yes
Certifications FCC, CE, ROHS, UL
EMC Protection 6kV Contact Discharge, 8kV Air Discharge ESD Protection

Advanced Security Features
802.1x Port-Based Network Access Control No
MAC Address Filtering No
VLAN Support No
