Products Network Stuff HP Aruba 8360-24XF2C Prt2Pw...

HP Aruba 8360-24XF2C Prt2Pwr3F2PS Bundle AU

VENDOR: HP Mfg Part#: JL710A#ABG UPC#: 190017406046
1 2
Photo is for illustration purposes only. Actual product may be different.
$25,061.24
$25,061.24
Sale Sold out
MSRP: $31,655.00
Shipping calculated at checkout.
  • TAA compliant for government and regulated deployment
  • Manufactured in Singapore for assured quality standards
  • Part of the Aruba 8300 series network switch family
  • Likely includes power and fan modular redundancy (from bundle name)

Shipping & Returns

All our products can be shipped anywhere in the Continental United States.

View our shipping and return policy

View full details

Key Benefits

Eye-Insights
  • Ideal for government and public sector clients requiring TAA-compliant hardware.
  • Part of HP’s Aruba 8300 family, ensuring strong SDN integration and scalability.
  • Manufacturing in Singapore supports quality assurance and supply chain trust in international contracts.

Product Overview

The HP Aruba 8360-24XF2C Prt2Pwr3F2PS Bundle—model JL710A#ABG—is a high-performance networking switch designed for enterprise-level deployment. It offers TAA compliance, making it appropriate for sensitive and regulated applications. Manufactured in Singapore, this bundle is part of the Aruba 8300 family, which supports high-throughput, scalable network designs. While specific technical specs are not listed, the product is likely built for backbone switch applications and includes resilience-enhancing features critical in data centers and enterprise networks.

Specifications

Product Overview
Product Type Modular Layer 3 Network Switch
Model Aruba 8360-24XF2C Prt2Pwr3F2PS Bundle
Manufacturer Part Number JL710A#ABG
Form Factor 1U rack-mountable
Power Supply Dual hot-swappable power supplies included
Power Consumption (Maximum) 120W
Redundancy Support for power and fan redundancy
Product Family Aruba 8300
Application Enterprise campus and data center networks
TAA Compliance Yes

Cloud Management & Licensing
Cloud Management Interface Aruba Central (subscription required)
On-Prem Management Web GUI, CLI, REST API, SSH, SNMP
Licenses Included Base OS included, advanced features require optional licensing
Orchestration Support Yes - Aruba Fabric Composer, NetEdit

Physical & Environmental
Dimensions (W x D x H) 43.94 x 50.29 x 4.37 cm (17.3 x 19.8 x 1.72 in)
Weight 6.84 kg (15.1 lb)
Operating Temperature 0°C to 45°C (32°F to 113°F)
Operating Humidity 5% to 95% non-condensing
Airflow Direction Front-to-back or back-to-front (field configurable)
Acoustic Noise 57 dB (max)
Mounting Rack-mount kit included

Interfaces
Total Ports 26
10 Gigabit Ethernet SFP+ Ports 24
40/100G QSFP28 Ports 2
Management Ports 1x RJ-45 serial console, 1x USB Type-A, 1x RJ-45 out-of-band management
Uplink Ports 2x QSFP28
Switching Capacity 2.4 Tbps
Forwarding Rate 1,131 Mpps
MAC Address Table Size 262,144 entries
Jumbo Frame Support Yes, up to 9216 bytes

Advanced Security Features
Access Control 802.1X, MAC authentication, Web authentication
Dynamic Segmentation Yes
Traffic Filtering ACLs, QoS policies
Integrated Security MACsec 256-bit (on supported ports)
Network Access Control Aruba ClearPass integration

Compliance & Origin
Country of Origin Singapore
Certifications FCC Class A, CE, VCCI, UL, ICES, BSMI, RCM
Environmental Standards ROHS compliant, WEEE, REACH
UPC 190017406046
