Samsung XHB-EP16FLAT2X3 LED Cabinet Display, Flat, 7000 nits, HDR

VENDOR: SAMSUNG Mfg Part#: LH160XHBCAE UPC#: 8806094571516
  • XHB-EP16FLAT2X3
1 1
Photo is for illustration purposes only. Actual product may be different.
$1,547.41
$1,547.41
Sale Sold out
MSRP: $2,066.18
Shipping calculated at checkout.
  • Display Type: LED Cabinet
  • Brightness: 7000 nits, ideal for high ambient light environments
  • Color Support: 281 trillion colors for rich, lifelike imagery
  • Refresh Rate: Ultra-smooth 7680 Hz for flicker-free visuals
  • Operating Temperature Range: -40°C to 55°C for extreme environments
  • HDR Capable: Expanded contrast and dynamic visuals

Shipping & Returns

All our products can be shipped anywhere in the Continental United States.

View our shipping and return policy

View full details

Key Benefits

Eye-Insights
  • Superior brightness and color fidelity ensure visibility and impact in daylight or harsh lighting.
  • Extreme operating temperature tolerance (-40°C to 55°C) increases deployment flexibility for indoor and outdoor signage.
  • TAA compliance makes it suitable for government or regulated sector contracts.

Product Overview

The Samsung XHB-EP16FLAT2X3, model LH160XHBCAE, is a professional-grade LED display cabinet built to excel in high-impact digital signage deployments. Its flat-panel design ensures a seamless, tileable configuration, ideal for creating expansive, continuous video walls. A peak brightness of 7000 nits and a 7000:1 contrast ratio make the panel highly visible even in direct sunlight. The panel supports a staggering 281 trillion colors and features a high 7680 Hz refresh rate, ensuring flicker-free motion in venues such as retail or public spaces.

Engineered for durability, the cabinet operates efficiently at 85 watts and supports 100~240 VAC input. Its wide thermal tolerance from -40°C to 55°C and TAA compliance make it suitable for mission-critical installations. Measuring 689.9 mm x 1035.4 mm and weighing 60.4 lbs., it offers deployment flexibility. While lacking integrated networking and stand, it provides ample HDR support and visual intensity for professional use cases.

Specifications

Product Overview
Product Type LED Cabinet Display
Form Factor Flat-panel modular cabinet
Model Number LH160XHBCAE
Display Technology Direct View LED
Contrast Ratio 7000:1
Color Support 281 Trillion Colors
Refresh Rate 7680 Hz
Pixel Pitch 16.43 mm
Viewing Angle (H/V) 160° / 115°
Brightness 7000 nits
HDR Support Yes
Weight 60.4 lbs
Power Consumption (Operational) 85 Watts
Power Requirements 100~240 VAC

Physical & Environmental
Width 689.9 mm
Height 1035.4 mm
Depth 100.9 mm
Minimum Operating Temperature -40°C
Maximum Operating Temperature 55°C

Cloud Management & Licensing
Cloud Management Not Supported
Licensing Model Not Applicable

Interfaces
Network Interface Not Integrated
Stand Included No

Compliance & Origin
Country of Origin Mexico
TAA Compliant Yes
