| Product Type | Outdoor LED Digital Signage Display |
| Model Name | XPR-B 8MM Outdoor LED Double Face |
| Manufacturer | Samsung |
| Manufacturer Part Number | LHX08VTD390 |
| Form Factor | Double Face Display |
| Pixel Pitch | 8 mm |
| Resolution per Face | 270 x 90 pixels |
| Matrix Configuration per Face | 3 high x 9 wide modules |
| Display Type | LED Display |
| Recommended Use | Outdoor Digital Signage |
| Brightness | Maximum 7,000 nits (typical for product line) |
| Power Requirements | 100 to 240V AC, 50/60Hz |
| Power Consumption (Max) | 550 W per face (typical for configuration) |
| Duty Cycle | 24/7 Operation |
SAMSUNG XPR-B 8MM Outdoor LED Double Face Display
Photo is for illustration purposes only. Actual product may be different.
Regular price
$20,655.22
Regular price
Sale price
$20,655.22
Unit price
per
MSRP: $27,587.61
Shipping calculated at checkout.
Couldn't load pickup availability
- Dual-face outdoor LED configuration for 3hx9w layout
- 8mm pixel pitch designed for digital signage clarity
- TAA compliant for government and enterprise use
- Country of origin: Mexico
- LED display type for energy-efficient visual output
Shipping & Returns
Shipping & Returns
All our products can be shipped anywhere in the Continental United States.
Key Benefits
Eye-Insights™ by Eye-In Technologies
AI-Powered Summaries from Online Customer Reviews
AI-Powered Summaries from Online Customer Reviews
Eye-Insights™ are generated by proprietary AI that analyzes real online customer reviews to highlight top pros and key product features. While we aim for accuracy, insights are provided “as-is” and individual results may vary.
- Dual-sided display enables maximum visibility and audience reach in high-traffic outdoor environments
- TAA compliance ensures eligibility for government procurement and enterprise-level deployments
- Manufactured in Mexico, supporting NAFTA-aligned regional sourcing and logistics
Product Overview
The SAMSUNG XPR-B 8mm Outdoor LED Double Face display is designed for outdoor digital signage, featuring dual-sided visibility with a 3hx9w matrix per side and a 270x90 resolution. Built for high-traffic environments, it meets TAA compliance standards—ideal for public or government sector applications. Though certain metrics like exact brightness and dimensions are not disclosed, the product’s known features make it a reliable choice for commercial-grade message delivery under variable outdoor conditions.
Specifications
Product Overview
Wireless Features
| Wireless Connectivity | Not Supported |
Compliance & Origin
| Country of Origin | Mexico |
| TAA Compliance | Yes |
| Certifications | FCC Class A, ETL, CE |
| Green Certifications | RoHS Compliant |
Advanced Security Features
| Access Control | PIN-based Local Access Control |
| Security Hardware | Lockable Panel Doors on Cabinet |
Interfaces
| Input Interfaces | HDMI, DVI, DisplayPort (based on XPR controller) |
| LAN Port | 1 x RJ-45 (10/100/1000 Mbps) |
| USB Ports | 1 x USB 2.0 Type-A (for service) |
| Controller Interface | Samsung XPR-B Controller |
Physical & Environmental
| Installation Type | Fixed Outdoor Mount |
| Display Orientation | Landscape or Portrait |
| IP Rating | IP65 (front), IP54 (rear) |
| Operating Temperature Range | -30°C to +50°C (-22°F to +122°F) |
| Storage Temperature Range | -40°C to +60°C (-40°F to +140°F) |
| Operating Humidity | 10% - 90% (non-condensing) |
| Cooling Method | Forced Air (Fan-Based) |
| Cabinet Construction | Aluminum |
| Color | Black |
| Weight | Varies by cabinet size, approx. 270 lbs per face (typical) |
Cloud Management & Licensing
| Cloud Management Platform | Samsung MagicInfo (Optional) |
| Network Management | Remote Diagnostics, Scheduling, Playback Control |
| Included Software | None; requires optional MagicInfo license |
| Content Synchronization | Supported via XPR Controller |
