STARTECH 4 Port USB to RS232/RS422/RS485 Serial Adapter

VENDOR: STARTECH Mfg Part#: ICUSB234854I UPC#: 065030878562
1 5
Photo is for illustration purposes only. Actual product may be different.
$285.45
$285.45
Sale Sold out
MSRP: $286.99
Shipping calculated at checkout.
  • 4 independently configurable serial ports supporting RS232, RS422, or RS485 (2-wire/4-wire)
  • Supports data transfer rates of up to 921.6 Kbps over USB 2.0 interface
  • Durable IP30-rated metal enclosure for industrial installation
  • Multiple mounting options: desktop, wall, and DIN rail
  • External power via included 12V adapter and 6 ft USB cable
  • TAA compliant and backed by a 2-year warranty

Shipping & Returns

All our products can be shipped anywhere in the Continental United States.

View our shipping and return policy

View full details

Key Benefits

Eye-Insights
  • Flexible multi-protocol support (RS232/RS422/RS485) enables broad device compatibility
  • Industrial-grade IP30-rated build with varied mounting options increases installation versatility
  • Includes essential accessories (USB cable and external power adapter), reducing additional procurement steps

Product Overview

Industrial 4 port serial hub 15kV Level 4 ESD - IP30 rating metal USB to serial adapter converter w/ each DB9 port set to RS232/RS422/RS485(2wire/4wire) baud rates up to 921.6Kbps - Desk/wall/DIN rail mount - 6ft USB cable - 12V power adapter/5V USB

Specifications

Product Overview
Product Type USB to Serial Adapter
Form Factor External
Enclosure Material Metal
Installation Type Desk, Wall, or DIN Rail Mountable
Power Requirements DC 12V (via AC adapter) / 5V via USB
Included Accessories 6ft USB cable, 12V power adapter
Baud Rate Support Up to 921.6 Kbps
Weight 0.6 lb (approximate)

Wireless Features
Wi-Fi Support

Compliance & Origin
Country of Origin Taiwan
TAA Compliant Yes
Certifications FCC, CE, RoHS, REACH
Warranty 2 Years

Advanced Security Features
Serial Port Isolation 2.5kV isolated serial ports
Surge Protection 15kV ESD Surge Protection
Tamper Protection

Interfaces
Host Interface USB 2.0 Type-B
Serial Ports 4 x DB9
Port Configuration Each port independently RS-232, RS-422 or RS-485 (2-wire/4-wire)
Data Bits 5, 6, 7, 8
Stop Bits 1, 1.5, 2
Parity None, Even, Odd, Mark, Space
Flow Control None, XON/XOFF, RTS/CTS
Max Data Transfer Rate 921.6 Kbps
Interface Chipset FTDI FT4232HL

Physical & Environmental
Width 4.6 in (117 mm)
Depth 5 in (127 mm)
Height 1 in (25 mm)
Mounting Options Desk, wall, DIN rail
Enclosure Color Black
Operating Temperature -10°C to 55°C (14°F to 131°F)
Storage Temperature -20°C to 85°C (-4°F to 185°F)
Relative Humidity 5% to 95% RH (non-condensing)
ESD Protection 15kV (Air), 8kV (Contact), Level 4
IP Rating IP30
