Eaton 93PM 208V 85kW N+1 UPS with Exhausted Comm Cards

VENDOR: EATON Mfg Part#: 9GH617A029A00R1
1 3
Photo is for illustration purposes only. Actual product may be different.
$65,700.28
$65,700.28
Sale Sold out
MSRP: $101,782.00
Shipping calculated at checkout.
  • 85kW double-conversion UPS with 208V power input
  • Tower form factor for vertical installation
  • Supports N+1 redundancy for failover protection
  • Compatible with multiple battery chemistries: VRLA, AGM, lithium, gel, and wet
  • TAA-compliant and manufactured in the United States
  • Height: 74 inches; Depth: 42 inches

Shipping & Returns

All our products can be shipped anywhere in the Continental United States.

View our shipping and returns policy

View full details

Key Benefits

Eye-Insights
  • Ensures continuous operation with double-conversion and N+1 redundancy for mission-critical systems
  • Flexible battery type support allows tailored backup solutions per operational needs
  • TAA-compliant and US-made, ideal for federal and regulated industry implementations

Product Overview

Eaton 93PM 208v 85kW N+1; all comm cards to exhaust

Specifications

Product Overview
Product Type Uninterruptible Power Supply (UPS)
Model 93PM
Power Device Type UPS
Form Factor Tower
UPS Technology Double Conversion (Online)
Rated Power Capacity 85 kW
Power Configuration N+1 Redundant
Input Voltage 208V
Output Voltage 208V
Input Frequency 50/60 Hz auto-sensing
Output Power Factor Unity (1.0)
Hot-Swappable Power Modules Yes
Efficiency Up to 97% in double-conversion mode
Energy Saver System (ESS) Yes

Wireless Features
Wireless Capability

Compliance & Origin
Country of Origin United States
TAA Compliant Yes
Certifications UL 1778, UL 60950, FCC Part 15 Class A, ENERGY STAR
RoHS Compliant Yes
REACH Compliant Yes

Advanced Security Features
User Authentication Yes (with role-based access control via network card)
Data Encryption on Communication Yes (HTTPS, SNMPv3 supported)
Syslog and Event Logging Yes
SNMPv3 Security Protocols Yes

Interfaces
Available Communication Slots 4 (fully populated - exhausted)
Built-in Network Management Port Yes
Serial Ports 1 x RS-232
USB Ports 1 x USB
Relay Output Contacts Yes
SNMP/Network Card Support Yes (cards installed)

Physical & Environmental
Height 74 in
Width 24 in
Depth 42 in
Unit Weight Approximately 1700 lbs (depending on configuration)
Operating Temperature 0°C to 40°C
Storage Temperature -25°C to 55°C
Operating Relative Humidity 5% to 95% (non-condensing)
Noise Level < 65 dBA at 1 meter
Cooling Method Forced air with fan redundancy

Cloud Management & Licensing
Remote Management Interface Eaton Intelligent Power Manager (IPM) compatible
Management Software Included Yes (via IPM)
Licensing Model Optional subscription license for advanced features
