Products Memory, Storage and Components Eaton EPDU G3HD MA 460P9W 4...

Eaton EPDU G3HD MA 460P9W 48A 10FT-END, 27 Outputs, Black, 1729mm

VENDOR: EATON Mfg Part#: EMACFL3XJA2A4K2
  • EATON
1 1
Photo is for illustration purposes only. Actual product may be different.
$2,718.69
$2,718.69
Sale Sold out
MSRP: $3,499.00
Shipping calculated at checkout.
  • 48A input via 6x DP-20A connectors for high current capacity
  • 21x IEC C13 and 6x IEC C19 output receptacles to support a variety of equipment
  • Extended 68.07-inch (1729mm) vertical length fits 38.9U rack space
  • Black enclosure for a clean, uniform data center aesthetic
  • TAA-compliant and manufactured in the United States for federal procurement
  • Designed for high-density deployments in critical IT environments

Shipping & Returns

All our products can be shipped anywhere in the Continental United States.

View our shipping and returns policy

View full details

Key Benefits

Eye-Insights
  • High output density with 27 total receptacles allows for flexible equipment power configurations.
  • TAA compliance and U.S. manufacturing make it ideal for government or enterprise contracts.
  • Compact vertical rack design maximizes space while supporting demanding power needs.

Product Overview

Eaton EPDU G3HD MA 460P9W 48A 10FT-END 6xDP-20A 21xC13,6xC19 LENGTH 68.07inch /1729mm/38.9U, COLOR BLACK

Specifications

Product Overview
Type Rackmount Power Distribution Unit (PDU)
Model Eaton EPDU G3 HD MA
Product Line EPDU G3 High Density Managed
Form Factor Vertical Rackmount (Zero U)
Mounting Orientation Vertical
Height (Rack Units) 38.9U
Length 1729 mm (68.07 inches)
Color Black
Weight 11.2 kg (24.7 lbs)
Power Requirements 3-Phase, 48A, 400V
Power Capacity 16.6 kW

Physical & Environmental
Dimensions (H x W x D) 1729 mm x 56 mm x 52 mm
Operating Temperature 0°C to 60°C (32°F to 140°F)
Storage Temperature -25°C to 65°C (-13°F to 149°F)
Operating Humidity 5% to 95% non-condensing
IP Rating IP20
Chassis Material Metal
Installation Type Toolless Mounting Buttons and Brackets

Cloud Management & Licensing
Management Interface Eaton Intelligent Power Manager (IPM), Web Interface, SNMP v1/v2c/v3
Remote Management Yes via Web, SNMP, CLI, Telnet, or REST API
Environmental Monitoring Support Yes (via optional sensors)
Firmware Upgradeable Yes, via Web interface or USB
User Access Levels Role-based (Admin, Operator, Viewer)

Interfaces
Input Connector Type IEC 60309 3P+N+PE 460P9W
Input Cord Length 10 ft
Input Phases 3-Phase
Input Current 48A
Output Connector Types 21 x IEC C13, 6 x IEC C19
Total Output Receptacles 27
Receptacle Orientation Alternating Phase
Max Output Power 16.6 kW
Network Interface 1 x Gigabit Ethernet RJ45
USB Ports 1 x USB-A for firmware/configuration

Compliance & Origin
Country of Origin United States
TAA Compliant Yes
RoHS Compliant Yes
Certifications UL 60950-1, CSA, CE, REACH

Advanced Security Features
User Authentication RADIUS, LDAP, local login
Encryption Protocols HTTPS, SSL, SSH
Event Logging Yes, with syslog support
Access Security User roles, password policies, secure provisioning
