Eaton EPDU G3HD MA 532P6W 24A UL with 6xSP-20A Fuse, 24xC13, 12xC39 Ports

VENDOR: EATON Mfg Part#: EMACFJ3XME5E5K2
1 1
Photo is for illustration purposes only. Actual product may be different.
$2,997.63
$2,997.63
Sale Sold out
MSRP: $3,858.00
Shipping calculated at checkout.
  • 24A UL (32A CE) rated power input via 532P6W plug
  • 6x SP-20A fused outlets for protected power distribution
  • 24x C13 and 12x C39 output receptacles for mixed-device support
  • 40.9U vertical mounting length (71.45 inches / 1815 mm)
  • Black enclosure for clean integration in rack environments
  • TAA compliance and Made in the USA origin

Shipping & Returns

All our products can be shipped anywhere in the Continental United States.

View our shipping and returns policy

View full details

Key Benefits

Eye-Insights
  • Supports high-density power distribution with 42 outlets in one unit (6x SP-20A, 24x C13, 12x C39)
  • Made in the USA and TAA-compliant for federal and international sourcing
  • dDesign accommodates a wide range of IT hardware with mixed receptacle types and fused circuits

Product Overview

Eaton EPDU G3HD MA 532P6W 24A UL (32A CE) 10FT-END 6xSP-20A-FUSE 24xC13,12xC39 LENGTH 71.45inch /1815mm/40.9U, COLOR BLACK

Specifications

Product Overview
Type Switched Rack Power Distribution Unit (PDU)
Form Factor Vertical (0U)
Input Power Requirements 208V/230V AC, 50/60 Hz
Maximum Input Current 24A UL / 32A CE
Input Plug Type NEMA L21-30P or IEC 532P6W (WYE input)
Power Output Capacity 7.36 kW @ 208V
Output Voltage 208/230V AC
Weight Approximately 18.2 lbs (8.25 kg)
Color Black
Circuit Protection 6x single pole 20A fuses

Wireless Features
Wi-Fi Support

Compliance & Origin
Country of Origin United States
TAA Compliant Yes
Certifications UL 60950-1, cULus Listed, CE, RoHS, REACH
Environmental Compliance RoHS, REACH

Advanced Security Features
User Authentication Role-based access control with LDAP/RADIUS
Encryption Support HTTPS, SSL, SSH
Access Control Per-outlet control with secure credentials
Auditing & Logging Secure logging with timestamped events

Interfaces
Total Outlets 36
Outlet Types 24x IEC C13, 12x Eaton C39 (Locking IEC Hybrid)
Network Interface 1x Ethernet (10/100 Mbps)
Serial Port 1x RJ-45 (RS-232 Serial)
USB Ports 1x USB Type A, 1x USB Type B (firmware/console)
Data Transfer Rate 10/100 Mbps Ethernet
Display Integrated OLED display with pixel-based diagnostics

Physical & Environmental
Dimensions (H x W x D) 71.45 in x 2.2 in x 2.0 in (1815 mm x 56 mm x 51 mm)
Vertical Rack Units 40.9U
Mounting Tool-less button or keyhole mount, vertical installation
Operating Temperature 0°C to 60°C (32°F to 140°F)
Storage Temperature -25°C to 70°C (-13°F to 158°F)
Relative Humidity 5% to 95% non-condensing
Elevation (Operating) Up to 3000 m

Cloud Management & Licensing
Remote Management Yes, via Eaton Gigabit Network Card
Web Management Interface HTML5 web interface
SNMP Support SNMP v1/v2c/v3
Supported Protocols HTTP, HTTPS, SNMP, Telnet, SSH, FTP, DHCP, RADIUS
Logging & Alerts Syslog, Email, SNMP traps
Firmware Upgradeability Yes – USB or network-based
Power Management Platform Eaton Intelligent Power Manager (optional)
