Eaton EPDU G3HD MA HW D48A 48A PDU, 30xC13, 3xC19, 6xDP-20A, 43.6U

VENDOR: EATON Mfg Part#: EMACHB5AJE3A2K2
  • EATON
1 1
Photo is for illustration purposes only. Actual product may be different.
$2,520.56
$2,520.56
Sale Sold out
MSRP: $3,244.00
Shipping calculated at checkout.
  • 48A power output capacity for heavy-duty applications
  • 6x DP-20A input connectors distribute high current
  • 30x C13 and 3x C19 output connectors for versatile equipment compatibility
  • Vertical form factor with 76.23" (1936mm) length and 43.6U height
  • Manufactured in the United States with TAA compliance
  • Black enclosure suited for standard enterprise rack aesthetics

Shipping & Returns

All our products can be shipped anywhere in the Continental United States.

View our shipping and returns policy

View full details

Key Benefits

Eye-Insights
  • Supports high-density power distribution with 48A capacity and six DP-20A inputs for demanding enterprise environments
  • Provides flexible equipment compatibility through 30 C13 and 3 C19 outputs, maximizing rack space utility
  • TAA-compliant and US-made construction ensures quality and eligibility for government procurement

Product Overview

Eaton EPDU G3HD MA HW D48A 48A 6xDP-20A 30xC13,3xC19 LENGTH 76.23/1936mm/43.6U, COLOR BLACK

Specifications

Product Overview
Type Power Distribution Unit (PDU)
Form Factor 0U Vertical Rackmount
Height (Rack Units) 43.6U
Weight 8.3 kg
Power Requirements Input Voltage: 208V/230V, Max Input Current: 48A
Color Black
Product Series ePDU G3 Managed High Density (HD)
Input Frequency 50/60 Hz

Wireless Features
Wi-Fi Support

Compliance & Origin
Country of Origin United States
TAA Compliant Yes
Certifications UL 60950-1, cUL, CE, RoHS, REACH
Environmental Compliance RoHS, WEEE
IP Rating IP20
REACH Compliance Yes
Mounting Compliance EIA-310E

Advanced Security Features
Encrypted Communication HTTPS, SNMPv3, SSH
Access Control Username/password, Role-based access
Audit Logging Yes

Interfaces
Input Connectors 6x NEMA L6-20P (via detachable cords)
Output Connectors 30x IEC C13, 3x IEC C19
Network Interface 1x Ethernet (RJ45) for management
Serial Interface 1x RS-232 (RJ45)
USB Ports 1x USB Type-A for firmware upgrade or local access
Overload Protection Per input branch via fuses or circuit breakers
Data Transfer Rate (Management) 10/100 Mbps

Physical & Environmental
Dimensions 1936 mm x 52 mm x 56 mm (H x W x D)
Mounting Vertical mount using toolless button kits or mounting brackets
Operating Temperature Range 0°C to 60°C
Storage Temperature Range -25°C to 60°C
Operating Humidity 5% to 95% non-condensing
Altitude (Maximum Operating) 3,000 meters
Construction Material Aluminum chassis
Cooling Passive (fanless)

Cloud Management & Licensing
Management Interface Eaton Intelligent Power Manager (IPM), Web UI, SNMP, Telnet, SSH
User Authentication LDAP, RADIUS, TACACS+
Remote Reboot Capability Yes (per outlet)
Power Monitoring Accuracy +/- 1%
Firmware Upgrade Upgradable via USB or network
Logging and Alerts Syslog, SNMP traps, email notifications
License Requirements No license required for standard management features
Cloud Integration Compatibility with Eaton Brightlayer and 3rd party DCIMs
