Eaton EPDU G3HD MA L6-30P 24A 37.3U Red PDU, 15xC13 3xC19 9xC39

VENDOR: EATON Mfg Part#: EMACMT3XJA6E3R2
1 1
Photo is for illustration purposes only. Actual product may be different.
$2,446.74
$2,446.74
Sale Sold out
MSRP: $3,149.00
Shipping calculated at checkout.
  • 24A input using L6-30P for robust power delivery
  • Rack-mountable 37.3U vertical design maximizes space
  • Output configuration: 15xC13, 3xC19, 9xC39 for versatile connectivity
  • Red-colored enclosure for easy visual identification
  • TAA compliant and manufactured in the United States

Shipping & Returns

All our products can be shipped anywhere in the Continental United States.

View our shipping and return policy

View full details

Key Benefits

Eye-Insights
  • Suited for mission-critical environments with TAA compliance ensuring regulatory compatibility
  • High outlet diversity (C13, C19, C39) supports a wide range of IT and network hardware
  • Vertical 37.3U rack design improves airflow and optimizes cabinet space

Product Overview

Eaton EPDU G3HD MA L6-30P 24A 10FT-END 3xDP-20A 15xC13,3xC19,9xC39 LENGTH 65.23/1657mm/37.3U, COLOR RED

Specifications

Product Overview
Type Rackmount Power Distribution Unit (PDU)
Form Factor Zero-U vertical rackmount
Mounting Orientation Vertical
Rack Units 37.3U
Weight 6.85 kg
Input Voltage 208V
Input Current 24A
Power Capacity 4.9 kW
Input Plug Type NEMA L6-30P
Cord Length 10 ft
Enclosure Color Red

Cloud Management & Licensing
Remote Management Yes
Management Interface Web, SNMP, Telnet, SSH
Network Connectivity Ethernet (RJ-45)
User Access Control Role-based access
Firmware Upgradeable Yes
Integration with Eaton Intelligent Power Manager Yes

Compliance & Origin
Country of Origin United States
TAA Compliance Yes
Certifications UL 60950-1, cUL
RoHS Compliance Yes

Interfaces
Output Connector Types 15 × IEC C13, 3 × IEC C19, 9 × IEC C39 (separable C19/C13)
Output Receptacle Quantity 27 outlets
Input Connector NEMA L6-30P
Number of Input Phases 1
Output Voltage 208V
Overload Protection Branch circuit monitoring with breakers
Overcurrent Protection Yes
Switchable Outlets Yes
Metering Type Outlet-level monitoring
Number of Circuits 3
Breaker Type 3 × Dual-pole 20A circuit breakers

Physical & Environmental
Dimensions (HxWxD) 1657 mm × 52 mm × 64 mm
Operating Temperature 0°C to 60°C
Storage Temperature -25°C to 70°C
Relative Humidity (operating) 5% to 95% non-condensing
Environmental Protection RoHS Compliant
