Eaton SQ432408-11023B 9390 BATT Power Accessory

VENDOR: EATON Mfg Part#: SQ432408-11023B
  • EATON
1 1
Photo is for illustration purposes only. Actual product may be different.
$11,000.00
$11,000.00
Sale Sold out
Shipping calculated at checkout.
  • Product Type: Power Accessories
  • Country of Origin: UNITED STATES
  • TAA Compliant: Yes

Shipping & Returns

All our products can be shipped anywhere in the Continental United States.

View our shipping and returns policy

View full details

Key Benefits

Eye-Insights
  • Made in the United States, ensuring compliance with stricter manufacturing and quality standards.
  • TAA compliance qualifies it for U.S. government and federal procurement contracts.
  • Built as part of Eaton’s integrated power ecosystem, enhancing critical infrastructure reliability.

Product Overview

Eaton NC NEW TECH SOLUTIONS EE504CBB04 JACKSON BARRACKS 9390 BATT

Specifications

Product Overview
Product Type Power Accessory
Compatible Series Eaton 9390 UPS
Form Factor Standalone Battery Cabinet
Power Requirements Configurable via 9390 UPS System
Typical Load Support Time Varies depending on load and configuration
Hot-Swappable Batteries Yes
Battery Type Valve-Regulated Lead Acid (VRLA)
Battery Voltage 480 VDC Nominal (typical for large frame 9390 systems)

Wireless Features
Wi-Fi Support

Compliance & Origin
Country of Origin UNITED STATES
TAA Compliant Yes
Certifications UL 1778, cUL, CE, FCC Class A
Seismic Compliance OSHPD (when configured with seismic option)
RoHS Compliant Yes

Advanced Security Features
Tamper Proof Design Key-lock access standard on cabinet
Security Management Role-based access provided through UPS network interface

Interfaces
Battery Connection Type Hardwired to UPS
Communication Interface Through UPS Control Interface

Physical & Environmental
Dimensions (H x W x D) 76 x 20.5 x 34 inches (typical)
Unit Weight 1600 lb (approximate for populated cabinet)
Operating Temperature 0°C to 40°C (32°F to 104°F)
Storage Temperature -15°C to 50°C (5°F to 122°F)
Operating Humidity 0% to 95% non-condensing
Altitude (Max Operating) Up to 1000m (without derating)
Cooling Method Convection-cooled
Color Black
Cabinet Type Seismic-rated enclosure (optional)
Installation Type Indoor

Cloud Management & Licensing
Remote Monitoring Compatible Yes (via 9390 UPS and optional Eaton Network Card-MS or IPM)
Cloud Integration Support Eaton Intelligent Power Manager (IPM) compatible
Battery Management Features Advanced battery management via UPS controller
Firmware Upgradeable Through UPS or network card module
