HighPoint R622A PCIe 2.0 x1 4-Channel SATA HBA with RAID Support

VENDOR: HIGHPOINT TECHNOLOGIES, INC. Mfg Part#: R622A UPC#: 643653622016
1 3
Photo is for illustration purposes only. Actual product may be different.
$14.00
$14.00
Sale Sold out
Shipping calculated at checkout.
  • 4-channel SATA HBA with two external eSATA ports
  • Supports RAID levels 0, 1, and JBOD for flexible configurations
  • PCIe 2.0 x1 interface for wide compatibility and performance
  • 6Gb/s data transfer rate per channel
  • Low-profile design ideal for space-constrained systems
  • MTBF rated at 920,585 hours indicating high reliability

Shipping & Returns

All our products can be shipped anywhere in the Continental United States.

View our shipping and returns policy

View full details

Key Benefits

Eye-Insights
  • RAID 0, 1, and JBOD support allows versatile storage setups for performance or redundancy.
  • Low-profile PCIe 2.0 x1 interface ensures compatibility with a wide range of compact systems.
  • MTBF of 920,585 hours ensures a long lifespan ideal for continuous operation environments.

Product Overview

The HighPoint R622A is a robust PCIe 2.0 x1 SATA HBA designed for users seeking a compact, efficient external storage solution. With a 4-channel configuration and dual eSATA ports, this adapter supports 6Gb/s data rates and RAID 0, 1, and JBOD modes. This low-profile card fits compact deployments and works seamlessly across Windows and Linux systems. With an MTBF of over 920,000 hours, it is well-suited for 24/7 environments and storage expansion in workstations or server arrays.

Specifications

Product Overview
Product Type Storage Controllers
Form Factor Low Profile
Interface Bus Type PCI Express 2.0 x1
Power Requirements 3.3V, 0.7A via PCIe slot
MTBF 920,585 Hours
Supported Operating Systems Windows and Linux

Physical & Environmental
Width 2.83 in (72 mm)
Height 2.66 in (67.5 mm)
Depth 0.06 in (1.5 mm)
Operating Temperature 5°C to 55°C
Storage Temperature -20°C to 70°C
Operating Humidity 10% to 85% non-condensing
Storage Humidity 5% to 95% non-condensing

Cloud Management & Licensing
Management Interface UEFI/BIOS utility and Web-based interface
Driver Support Windows 11/10, Windows Server, Linux Kernel 3.x/4.x/5.x
Bundled Software RAID Management Software (Web GUI)
Firmware Upgradeability Yes, via Web Interface

Interfaces
External Ports 2 x eSATA
Total Channel Count 4
Data Transfer Rate 6 Gb/s
Controller Interface Type Serial ATA
Supported RAID Levels RAID 0, RAID 1, JBOD

Compliance & Origin
Country of Origin China
TAA Compliant No
RoHS Compliant Yes
CE Certified Yes
FCC Compliant Yes
WEEE Compliant Yes

Advanced Security Features
RAID Protection Modes RAID 1 for Redundancy
Drive Health Monitoring Yes
SMART Monitoring Support Yes
Automatic Drive Rebuilding Yes
Write Protection Support Yes (via software configuration)
