Products Memory, Storage and Components HighPoint RM110-820P USB-C ...

HighPoint RM110-820P USB-C 3.2 NVMe Enclosure, 20Gbps, OS RAID Ready

VENDOR: HIGHPOINT TECHNOLOGIES, INC. Mfg Part#: RM110-820P UPC#: 643653111480
1 3
Photo is for illustration purposes only. Actual product may be different.
$719.00
$719.00
Sale Sold out
Shipping calculated at checkout.
  • USB-C 3.2 Gen2x2 interface supports up to 20Gbps data transfer rates
  • Includes 8-port USB-C 3.2 20G controller card for system expansion
  • OS RAID ready with support for Windows 11, macOS, Linux, and VMware ESXi
  • Compact dimensions: 4.13” x 2.1” x 0.68” to fit tight workspace environments
  • Low power draw: 12W at 5V ensures energy-efficient performance
  • LED indicator lights for device status monitoring

Shipping & Returns

All our products can be shipped anywhere in the Continental United States.

View our shipping and returns policy

View full details

Key Benefits

Eye-Insights
  • High-speed USB 3.2 Gen2x2 connectivity enables up to 20Gbps transfer rates for demanding applications
  • Cross-platform OS support enhances deployment flexibility across Windows, macOS, Linux, and ESXi environments
  • Bundled 8-port USB-C controller card expands system I/O capabilities for scalable performance

Product Overview

The HighPoint RM110-820P is a professional-grade external NVMe enclosure engineered for USB-C 3.2 Gen2x2 connectivity, delivering 20Gbps speeds compatible with Windows, macOS, Linux, and VMware ESXi. It includes an 8-port USB-C 3.2 controller card for scalable I/O support, OS RAID readiness, and features LED indicators for system status. Built for low power consumption at 12W, the compact unit (4.13" x 2.1" x 0.68") is ideal for professional workstations needing fast, external storage expansion.

Specifications

Product Overview
Product Type External NVMe Storage Enclosure
Model RM110-820P
Included Controller 8-Port USB-C 3.2 Controller Card
Form Factor Compact External Enclosure
OS RAID Ready Yes
Power Consumption 12W
Power Voltage Required 5V DC
LED Status Indicators Yes
Enclosure Type Aluminum
Cooling Mechanism Passive Cooling

Wireless Features

Compliance & Origin
Country of Origin China
RoHS Compliance Yes
TAA Compliant No
Certifications CE, FCC, RoHS
Warranty 1 Year Manufacturer Warranty

Advanced Security Features

Interfaces
Host Interface USB 3.2 Gen 2x2
Host Connector Type USB Type-C
Data Transfer Rate 20 Gbps
Drive Interface M.2 NVMe (PCIe 3.0 x4)
Number of Drive Bays 1 x M.2 2280
Supported Drive Form Factors M.2 2280
USB Controller USB-C 3.2 Gen2x2 Controller
Compatible USB Ports USB 3.2 Gen 2 / Gen 2x2

Physical & Environmental
Width 4.13 inches (105 mm)
Depth 2.1 inches (53 mm)
Height 0.68 inches (17.5 mm)
Material Aluminum Alloy
Operating Temperature 0°C to 40°C
Storage Temperature -20°C to 70°C
Operating Humidity 5% to 85% RH (non-condensing)
Color Black
Weight Approximately 100g

Cloud Management & Licensing
Management Interface OS Based (No Proprietary UI)
Software Compatibility Windows 10/11, macOS, Linux, VMware ESXi
