HP Aruba 6200F 12G CL4 2G/2SFP+TAA Switch PDU

VENDOR: HP Mfg Part#: R8V13A#B2B
1 5
Photo is for illustration purposes only. Actual product may be different.
$2,350.56
$2,350.56
Sale Sold out
MSRP: $2,969.00
Shipping calculated at checkout.
  • 12 Gbps switching capacity for robust network throughput
  • 16-port configuration supporting Gigabit Ethernet
  • SFP+ uplink capabilities for high-speed fiber connectivity
  • TAA-compliant for use in U.S. government or regulated markets
  • Made in the United States to support local manufacturing and compliance
  • Comes integrated with PDU features for centralized resource handling

Shipping & Returns

All our products can be shipped anywhere in the Continental United States.

View our shipping and returns policy

View full details

Key Benefits

Eye-Insights
  • TAA compliance and U.S.-based manufacturing make it suitable for federal and regulated environments
  • Flexible 16-port configuration with SFP+ uplinks enables deployment in diverse networking scenarios
  • 12 Gbps switching capacity supports modern network traffic demands with reliability

Product Overview

The HP Aruba 6200F 12G CL4 2G/2SFP+TAA Switch PDU is engineered to meet the high-performance demands of contemporary enterprise networks. It supports a switching capacity of 12 Gbps, ensuring reliable data flow across critical applications. With 16 Gigabit Ethernet ports and integrated SFP+ support, this switch provides enhanced connectivity for both copper and fiber installations, accommodating a range of deployment scenarios and network configurations.

This model is TAA-compliant and manufactured in the United States, making it well-suited for federal contracts or compliance-sensitive deployments. Its flexible port configuration supports both copper Ethernet and fiber-optic uplinks, maximizing performance and scaling potential in distributed or core network environments. The inclusion of Power Distribution Unit (PDU) capabilities underscores its usefulness in centralized network operations, contributing to efficient power management.

While more detailed technical specifications are not provided, the Aruba 6200F platform is recognized for delivering a reliable and secure network infrastructure. Businesses seeking a switch with a balance of scalability, compliance, and bandwidth performance will find this unit especially compelling for growth or modernization projects.

Specifications

Product Overview
Product Type Managed Switch
Model Aruba 6200F 12G CL4 2G/2SFP+TAA Switch PDU
Manufacturer HP
Manufacturer Part Number R8V13A#B2B
Form Factor Rack-mountable
Power Supply Internal
Power Consumption (Maximum) 28 W
Switching Capacity 56 Gbps
Forwarding Rate 41.7 Mpps
Packet Buffer Size 1.5 MB
Reliability (MTBF) 120 years

Wireless Features
Wireless Support

Compliance & Origin
Country of Origin United States
TAA Compliant Yes
Certifications UL, CE, FCC Class A, VCCI, CCC, RoHS
Safety Standards UL 60950-1, IEC 60950-1
EMI Standards EN 55032 Class A, EN 55024

Advanced Security Features
Access Control Lists (ACLs) Yes
IEEE 802.1X Support Yes
MAC-based Authentication Yes
Port Security Yes
DHCP Snooping Yes
Dynamic ARP Protection Yes
IP Source Guard Yes
Secure Management Access SSH, HTTPS, SNMPv3

Interfaces
Total Number of Ports 16
10/100/1000Base-T Ports 12
SFP+ Ports 2
10GBase-T Ports 2
Management Port 1 x RJ-45 out-of-band
Console Port 1 x USB-C, 1 x RJ-45
Auto-MDI/MDI-X Yes
Port Mirroring Yes
Jumbo Frame Support Up to 9216 bytes

Physical & Environmental
Dimensions (W x D x H) 44 x 24.8 x 4.45 cm (17.32 x 9.76 x 1.75 in)
Weight 3.7 kg (8.16 lb)
Operating Temperature 0°C to 45°C (32°F to 113°F)
Storage Temperature -40°C to 70°C (-40°F to 158°F)
Operating Humidity 10% to 95% (non-condensing)
Storage Humidity 5% to 95% (non-condensing)
Acoustic Power Emissions 47.2 dB
Cooling Fanless

Cloud Management & Licensing
Management Interface Aruba Central (cloud), Web GUI, CLI, REST API
Switch OS Aruba AOS-CX
Licensing Requirement Optional for advanced features
Cloud Management Support Yes, via Aruba Central
