HP Aruba 6200M 24G CL4 PoE 4SFP+ Reman Switch R8Q68AR

VENDOR: HP Mfg Part#: R8Q68AR
1 2
Photo is for illustration purposes only. Actual product may be different.
$4,292.59
$4,292.59
Sale Sold out
MSRP: $5,422.00
Shipping calculated at checkout.
  • 24x 10/100/1000BASE-T Class 4 PoE ports, each supporting up to 30W
  • 4x 1G/10G SFP+ uplinks for high-speed connectivity
  • Supports IEEE 802.3af and 802.3at PoE standards
  • Layer 3 advanced routing with ARM Cortex A72 processor
  • 76W maximum power consumption for efficient operation
  • Limited Lifetime Warranty and TAA compliance

Shipping & Returns

All our products can be shipped anywhere in the Continental United States.

View our shipping and returns policy

View full details

Key Benefits

Eye-Insights
  • Delivers powerful PoE capabilities with 740W total budget for dense device integration
  • Layer 3 routing with enterprise-grade uplinks and management options for scalable deployment
  • Remanufactured by HP with lifetime warranty, balancing performance and value

Product Overview

The HP Aruba 6200M 24G CL4 PoE 4SFP+ Reman Switch (R8Q68AR) is a Layer 3 enterprise-grade switch with 24 Class 4 PoE ports supporting up to 30W per device, alongside four 1G/10G SFP+ uplinks for high-speed connectivity. The switch features robust routing capability, powered by an ARM Cortex A72 processor and an advanced management interface which includes RJ-45 and USB console ports. It has a 740W PoE budget, is TAA compliant, and operates at a peak power draw of just 76W, providing efficiency and network scalability. Ideal for enterprise and campus edge deployments, this remanufactured model includes a limited lifetime warranty for added peace of mind.

Specifications

Product Overview
Product Type Managed Layer 3 Switch
Form Factor 1U Rack-mountable
Processor Type ARM Cortex A72
Power Consumption (Operational) 76 Watt
Maximum Power Consumption 76 Watt
PoE Power Budget 740W
Power Requirements 100V-120V / 200V-240V AC
PoE Type Class 4 PoE (IEEE 802.3af, 802.3at)
Switching Capacity 176 Gbps
Forwarding Rate 130.9 Mpps
Warranty Limited Lifetime Warranty

Cloud Management & Licensing
Management Interface Aruba Central, Web GUI, CLI, REST API
Cloud-Based Management Supported via Aruba Central
Smart Management Features Yes (via Aruba AOS-CX)
Switch Software ArubaOS-CX
Licensing Model Includes Basic License, Add-ons Available

Physical & Environmental
Width 17.42 in
Depth 15.11 in
Height 1.73 in
Weight 13.25 lbs
Operating Temperature 32°F to 122°F (0°C to 50°C)
Storage Temperature -40°F to 158°F (-40°C to 70°C)
Operating Humidity 10% to 95% (non-condensing)
Mounting Type Rack-mount 1U (rack ears included)
Fanless No (Active cooling)

Interfaces
Total Ports 28
10/100/1000 RJ-45 Ports 24
SFP+ Ports 4 x 1G/10G SFP+
Uplink Support 4 x SFP+ (1G/10G)
Console Ports 1 x RJ-45, 1 x USB-C
Out-of-Band Management Port 1 x 10/100/1000 RJ-45 (OOBM)
USB Ports 1 x USB Type-A Host
Data Link Protocol Gigabit Ethernet
Throughput 130.9 Mpps
MAC Address Table Size 32,000 entries
Packet Buffer Size 12 MB

Advanced Security Features
Access Control 802.1X, MAC authentication, Web-based authentication
Security Features DHCP Snooping, Dynamic ARP Protection, IP Source Guard
Segmentation Private VLAN, VLAN ACLs
Traffic Filtering Layer 2-4 ACLs
Secure Management SSH, SNMPv3, HTTPS, RADIUS/TACACS+

Compliance & Origin
Country of Origin United States
TAA Compliance Yes
Certifications UL, CE, FCC Class A, RoHS, WEEE, REACH
Green Compliance RoHS Compliant
