HP Aruba 6400 48P 1G CL4 PoE 4SFP56 V2 Network Module

VENDOR: HP Mfg Part#: R0X39C UPC#: 190017537474
1 4
Photo is for illustration purposes only. Actual product may be different.
$10,156.70
$10,156.70
Sale Sold out
MSRP: $12,829.00
Shipping calculated at checkout.
  • 48-port 1GbE Class 4 PoE capability for powering connected devices directly
  • 4-port SFP56 uplink support for high-speed fiber connectivity
  • Plug-in module form factor designed for compatible Aruba platforms
  • Supports Gigabit Ethernet transport and data link protocols
  • TAA compliant, suitable for government and regulated use cases
  • Compact dimensions: 12.4" (W) x 17.3" (D) x 1.7" (H)

Shipping & Returns

All our products can be shipped anywhere in the Continental United States.

View our shipping and return policy

View full details

Key Benefits

Eye-Insights
  • Offers high port density with PoE support, ideal for enterprise access layer consolidation
  • SFP56 ports provide enhanced uplink flexibility for high-throughput environments
  • TAA compliance makes it deployable in U.S. government and federal projects

Product Overview

The HP Aruba 6400 48P 1G CL4 PoE 4SFP56 V2 Module (R0X39C) is a high-performance plug-in module featuring 48 1GbE Class 4 PoE ports and 4 SFP56 uplink ports for robust network scalability. Designed for use with select Aruba systems, it supports Gigabit Ethernet protocols and ensures high-density connectivity with TAA compliance. Its compact form factor and compliance for enterprise and government environments make it ideal for modern, large-scale infrastructure deployments.

Specifications

Product Overview
Product Type Module
Form Factor Plug-In Module
Weight 4.08 lbs (1.85 kg)
Power Requirements Up to 30W per port (802.3at Class 4 PoE), overall module draw depends on utilization

Wireless Features
Wireless Capabilities

Compliance & Origin
TAA Compliant Yes
Country of Origin Singapore
Certifications UL, cUL, CE, FCC Class A, RoHS, VCCI, BSMI, RCM
EMC Standards EN 55032 Class A, EN 55024
Safety Standards IEC 60950-1, IEC 62368-1

Advanced Security Features
Access Control 802.1X, MAC Authentication, Web Authentication
Network Security Dynamic Segmentation, Role-based access
MACSec Support Yes (on supported SFP56 uplinks)
Port Security Yes
DHCP Snooping Yes
ARP Protection Yes
IP Source Guard Yes

Interfaces
Port Count 52 Total
PoE Port Count 48
Uplink Port Count 4
PoE Standard IEEE 802.3at (PoE+), Class 4
Interface Type SFP56, RJ-45
Data Transfer Rate 1 Gbps (per port)
Total Switching Capacity Up to 176 Gbps per slot (dependent on chassis configuration)
Transport Protocol Gigabit Ethernet
Data Link Protocol Gigabit Ethernet
Connector Type 48 x RJ-45, 4 x SFP56

Physical & Environmental
Width 12.4 in (31.5 cm)
Depth 17.3 in (43.9 cm)
Height 1.7 in (4.3 cm)
Operating Temperature 32°F to 131°F (0°C to 55°C)
Storage Temperature -40°F to 158°F (-40°C to 70°C)
Operating Humidity 5% to 95%, non-condensing
Storage Humidity 5% to 95%, non-condensing
Cooling Chassis-based airflow, passive module

Cloud Management & Licensing
Management Interface Aruba AOS-CX Managed via Aruba Central or CLI/Web UI
Cloud Management Support Yes, via Aruba Central
License Requirements Optional licensing for advanced features (Aruba Central subscriptions)
