HP Aruba 8360-24XF2C 24-Port L3 Managed Switch JL711A#ACD

VENDOR: HP Mfg Part#: JL711A#ACD UPC#: 190017406329
1 1
Photo is for illustration purposes only. Actual product may be different.
$25,061.24
$25,061.24
Sale Sold out
MSRP: $31,655.00
Shipping calculated at checkout.
  • 24 x 1/10 Gigabit SFP+ ports and 2 x 40/100 Gigabit QSFP+/QSFP28 uplinks
  • Switching capacity of 880 Gbps and ultra-low 1 µs latency
  • Support for advanced routing protocols such as BGP, OSPF, VRRP, and PIM-SM
  • Redundant hot-swappable fans and dual N+1 power supplies
  • Security features including FIPS 140-2, MACsec, RADIUS, and TACACS+
  • Remote management via SNMPv3, CLI, SSH, and SFTP

Shipping & Returns

All our products can be shipped anywhere in the Continental United States.

View our shipping and returns policy

View full details

Key Benefits

Eye-Insights
  • Enterprise-grade performance with 880 Gbps switching capacity and 100G uplinks supports high-throughput demands in data centers.
  • Built-in high availability with redundant fans and N+1 power supply ensures maximum uptime for mission-critical networks.
  • Robust network security and management capabilities with advanced routing protocols, encryption standards, and remote access tools streamline operations and reduce risk.

Product Overview

The HP Aruba CX 8360-24XF2C (JL711A#ACD) is a high-capacity Layer 3 managed switch designed for enterprise networks and data center applications. It features 24 SFP/SFP+ and 2 QSFP+/QSFP28 ports, offering up to 880 Gbps switching capacity and 1 µs latency. Network flexibility is enhanced through extensive routing protocol support including BGP, OSPF, VRRP, and PIM-SM. Built-in redundant power (N+1) and hot-swappable fan trays ensure continuous operation. This model supports MACsec encryption, 9KB Jumbo Frames, and 4094 VLANs for scalable and secure networking. With a limited lifetime warranty and an MTBF of over 375,000 hours, the 8360-24XF2C is a robust investment for modern network infrastructures.

Specifications

Product Overview
Device Type Layer 3 Managed Switch
Form Factor Rack-mountable - 1U
Weight 17.79 lbs
Power Requirements AC 120/230 V (47 - 63 Hz)
Power Provided 550 Watt
Power Redundancy Yes
Power Redundancy Scheme N+1
MTBF 375668 hours
Included Accessories 3 fan trays
Processor 1.8 GHz
RAM 16 GB
Flash Memory 32 GB

Wireless Features

Compliance & Origin
TAA Compliant Yes
Certifications FCC, EN, ISO, IEEE, UL, RoHS, ICES, VCCI, CNS
Directive Compliance EMC 2014/30/EU, Directive 2014/35/EU
Country of Origin Singapore

Advanced Security Features
MACsec Encryption Supported
Encryption Algorithm FIPS 140-2
Authentication Methods SSH, SSH2, RADIUS, TACACS+
Access Control Features ACL support, DHCP snooping, port security
Traffic Security IGMP/MLD snooping, packet storm protection, BPDU guard
Advanced Features Flow control, QoS, DCB, SP, LACP, congestion control, sFlow, IPv6, STP/RSTP/MSTP, VSX, VXLAN, ERPS, Loopback detection

Interfaces
SFP+/SFP Ports 24 x 1/10 Gigabit SFP+
QSFP+/QSFP28 Ports 2 x 40/100 Gigabit QSFP+/QSFP28
Console Ports 1 x Serial Console, 1 x USB-C Console
Management Ports 1 x RJ-45, 2 x USB
Switching Capacity 880 Gbps
Throughput 2 Mbps
Latency 1 µs
Jumbo Frame Support 9KB
VLAN Support 4094 VLANs

Physical & Environmental
Dimensions (W x D x H) 17.4 in x 16 in x 1.7 in
Min Operating Temperature 32 °F
Max Operating Temperature 104 °F
Humidity Range Operating 15 - 95% (non-condensing)
Humidity Range Storage 15 - 95% (non-condensing)

Cloud Management & Licensing
Management Features Web GUI, CLI, SNMP, SSH, RMON, TFTP, SFTP, NTP
Remote Management Protocols SNMP v1/v2c/v3, RMON, TFTP, SSH, SFTP, CLI, ICMP, IPv4/IPv6
