HP Aruba 8360-24XF2C 26-Port 10GbE Switch Bundle (JL710A#ACQ)

VENDOR: HP Mfg Part#: JL710A#ACQ UPC#: 190017406138
1 3
Photo is for illustration purposes only. Actual product may be different.
$25,061.24
$25,061.24
Sale Sold out
MSRP: $31,655.00
Shipping calculated at checkout.
  • 26-port wired switch with 10 Gigabit Ethernet connectivity
  • Total system memory: 16GB
  • Onboard flash memory: 32GB
  • Trade Agreements Act (TAA) compliant
  • Country of origin: Singapore

Shipping & Returns

All our products can be shipped anywhere in the Continental United States.

View our shipping and returns policy

View full details

Key Benefits

Eye-Insights
  • Delivers enterprise-grade 10GbE wired connectivity for scalable network growth.
  • Equipped with high memory capacity (16GB RAM and 32GB flash) for demanding applications and future firmware needs.
  • TAA compliance ensures eligibility for use in government and federally regulated projects.

Product Overview

The HP Aruba 8360-24XF2C switch bundle (JL710A#ACQ) provides 26 high-speed ports with 10 Gigabit Ethernet connectivity, ideal for demanding enterprise environments. With 16GB memory and 32GB flash storage, it ensures reliable, scalable networking operations. TAA compliance and manufacturing origin in Singapore support government-grade deployment needs. This switch is suited for high-throughput aggregation and top-of-rack roles in campus and data center infrastructures.

Specifications

Product Overview
Product Type Managed Ethernet Switch
Model Aruba CX 8360-24XF2C
Bundle Part Number JL710A#ACQ
Switching Capacity 1.2 Tbps
Forwarding Rate 595 Mpps
Form Factor 1U Rack-mountable
Weight 9.6 lb (4.35 kg)
Power Supply Dual field-replaceable power supplies included
Flash Memory 32 GB
System Memory (RAM) 16 GB
Redundancy Redundant power and fans

Physical & Environmental
Dimensions (W x D x H) 17.42 x 12.64 x 1.73 in (442.5 x 321.2 x 44 mm)
Operating Temperature 32°F to 113°F (0°C to 45°C)
Storage Temperature -40°F to 158°F (-40°C to 70°C)
Operating Humidity 15% to 95% non-condensing
Maximum Altitude 10,000 ft (3,048 m)
Acoustic Noise Level ≤ 62 dB

Cloud Management & Licensing
Management Interface Aruba AOS-CX CLI, GUI, REST API
Cloud Management Supported via Aruba Central (optional license)
Zero-Touch Provisioning Supported
Monitoring Built-in Aruba Network Analytics Engine (NAE)
License Requirement Base OS included; enhanced features require additional licensing

Interfaces
Total Ports 26
SFP+ Ports 24 x 1/10GbE SFP+
Combo Ports 2 x 1/10GBASE-T or SFP+
Out-of-Band Management Port 1 x RJ-45 Ethernet
Console Ports 1 x RJ-45, 1 x Micro-USB
USB Port 1 x USB Type-A (for file transfer and storage)

Compliance & Origin
TAA Compliant Yes
Country of Origin Singapore
Certifications UL, cUL, CE, FCC, VCCI, BSMI, RCM, RoHS
Energy Efficiency ENERGY STAR® Qualified

Advanced Security Features
Access Control Port-based and user-based 802.1X
MACsec Encryption Supported (IEEE 802.1AE)
ACLs Ingress and egress ACLs
Dynamic Segmentation Supported
Secure Boot Hardware-based secure boot and trusted platform module (TPM)
DHCP Snooping Supported
IP Source Guard Supported
Control Plane Policing Supported
