HP Aruba 8360-24XF2C 26-Port 10GbE Switch Bundle (JL711A#ACF)

VENDOR: HP Mfg Part#: JL711A#ACF UPC#: 190017406343
1 3
Photo is for illustration purposes only. Actual product may be different.
$25,061.24
$25,061.24
Sale Sold out
MSRP: $31,655.00
Shipping calculated at checkout.
  • 26 wired networking ports with 10 Gigabit Ethernet support
  • 16GB memory integrated for higher data handling
  • 32GB storage for configuration and operational tasks
  • TAA compliant for government-use suitability
  • Manufactured in Singapore, indicating reliable build origin

Shipping & Returns

All our products can be shipped anywhere in the Continental United States.

View our shipping and returns policy

View full details

Key Benefits

Eye-Insights
  • Provides 10Gbps bandwidth across 26 ports, making it ideal for high-performance enterprise networking
  • TAA compliance ensures it meets regulatory requirements for U.S. government and federal deployments
  • Includes both memory and storage capacity for managing complex configurations and sustained uptime

Product Overview

The HP Aruba 8360-24XF2C Pwr2Prt3F2PS Bundle (JL711A#ACF) is an enterprise-grade 10GbE switch offering 26 wired ports for high-capacity, efficient networking. With 16GB memory and 32GB storage, this TAA-compliant device is ideal for data-intensive enterprise environments such as data centers and hybrid cloud deployments. While detailed configuration data is unavailable, the switch’s performance profile aligns it with scalable, modular infrastructure needs.

Specifications

Product Overview
Product Type Layer 3 Managed Switch
Model Aruba 8360-24XF2C
Part Number JL711A#ACF
Form Factor 1U Rack-mountable
Dimensions (W x D x H) 17.42 x 17.8 x 1.73 in (442.5 x 452 x 44 mm)
Weight 15.2 lbs (6.9 kg)
Power Supply Dual hot-swappable 680W AC power supplies included
Power Consumption Approx. 150W (maximum)
Switching Capacity 2 Tbps
Forwarding Rate 1,488 Mpps
Memory 16 GB DDR4
Storage 32 GB eMMC

Wireless Features
Wireless Capability

Compliance & Origin
TAA Compliant Yes
Country of Origin Singapore
Certifications UL, cUL, CB, FCC Class A, VCCI Class A, CE, CCC
RoHS Compliant Yes
REACH Compliant Yes
WEEE Compliant Yes

Advanced Security Features
Access Control Lists (ACLs) Yes
MACsec Encryption Yes, 802.1AE
DHCP Snooping Yes
Dynamic ARP Protection Yes
IP Source Guard Yes
802.1X Authentication Yes
RADIUS/TACACS+ Support Yes

Interfaces
Total Ports 26
10 Gigabit SFP+ Ports 24 x 1/10GbE SFP+
40 Gigabit QSFP+ Ports 2 x 40GbE QSFP+
Management Ports 1 x RJ-45 serial console; 1 x USB Type-A; 1 x RJ-45 out-of-band management port
Auto Negotiation Yes
Jumbo Frame Support Yes, up to 9216 bytes
Ethernet Standards IEEE 802.3, 802.3u, 802.3ab, 802.3z, 802.3ae, 802.3x, 802.1Q, 802.1p

Physical & Environmental
Operating Temperature 32°F to 113°F (0°C to 45°C)
Storage Temperature -40°F to 158°F (-40°C to 70°C)
Operating Humidity 5% to 95% (non-condensing)
MTBF Over 1,000,000 hours
Acoustic Noise 56 dB (maximum)
Cooling Front-to-back airflow with hot-swappable fans

Cloud Management & Licensing
Management Interface ArubaOS-CX CLI, REST API, Web GUI
Cloud Management Supported via Aruba Central
Stacking Capability Yes, VSX High Availability Supported
Licensing Model Subscription-based for Aruba Central
