Products Network Stuff HP Aruba 8360-32Y4C v2 Swit...

HP Aruba 8360-32Y4C v2 Switch, 100GbE, 36-Port, JL717C

VENDOR: HP Mfg Part#: JL717C UPC#: 190017589916
1 1
Photo is for illustration purposes only. Actual product may be different.
$25,496.67
$25,496.67
Sale Sold out
MSRP: $32,205.00
Shipping calculated at checkout.
  • Advanced Layer 3 routing capabilities for efficient network management
  • Up to 36 high-speed ports with 100GbE support via QSFP+/QSFP28
  • 1.8 GHz quad-core 64-bit CPU with 16 GB RAM and 32 GB storage
  • Power-efficient design with 110W max operational consumption
  • High availability with industry-leading VSX redundancy architecture
  • TAA compliant with limited lifetime warranty coverage

Shipping & Returns

All our products can be shipped anywhere in the Continental United States.

View our shipping and returns policy

View full details

Key Benefits

Eye-Insights
  • Ideal for high-performance data centers or enterprise cores needing advanced Layer 3 switching and VSX redundancy
  • Extensive port flexibility allows mixed 1GbE/10GbE/100GbE environments to be consolidated in one platform
  • TAA compliance and lifetime warranty make it a secure long-term investment for government and regulated industries

Product Overview

The HP Aruba 8360-32Y4C v2 Switch (JL717C) delivers high-performance Layer 3 switching with support for up to 100GbE via 36 ports. Designed for scalable and resilient enterprise deployments, it incorporates a 1.8 GHz 4-core CPU, 16 GB RAM, and 32 GB storage for robust control processing. The switch offers advanced interface flexibility with mixed fiber and copper options and provides VSX redundancy for maximum uptime. With 110W operational power and TAA compliance, it’s well-suited for commercial and government networks.

Specifications

Product Overview
Manufacturer HP
Model Name HP Aruba 8360-32Y4C v2
Manufacturer Part Number JL717C
Device Type Layer 3 Managed Ethernet Switch
Series Aruba CX 8360 v2 Switch Series
Form Factor 1U Rack-mountable
Weight 23.65 lbs
Power Consumption (Operational) 110 Watts
Maximum Power Consumption 110 Watts
CPU 1.8 GHz quad-core ARM Cortex-A72
System Memory (RAM) 16 GB
Storage 32 GB eMMC
Redundancy VSX redundancy support
Warranty Limited Lifetime Warranty

Wireless Features

Compliance & Origin
Country of Origin Singapore
TAA Compliant Yes
Certifications FCC Class A, CE, UL, CB, VCCI, BSMI, CCC
RoHS Compliant Yes

Advanced Security Features
Network Security MACsec, DHCP snooping, Dynamic ARP Protection, IP Source Guard
Access Control 802.1X, port security, RADIUS, TACACS+
Policy Enforcement User-based access control via Aruba Dynamic Segmentation
Secure Management SSH, HTTPS, SNMPv3 for secure device access
Traffic Filtering ACLs (Access Control Lists) for packet filtering

Interfaces
Total Number of Ports 36
Port Type QSFP+/QSFP28
Uplink Ports 4 x 40GbE/100GbE (QSFP+/QSFP28)
Data Transfer Rate 100 Gbps
Data Link Protocol 100 Gigabit Ethernet
Breakout Support Supports 4x10G/25G breakout cables
SFP/SFP+ Support Optional 1GBASE-T SFP and 10GBASE-T SFP+
Transceiver Support QSFP+/QSFP28, SFP/SFP+
Management Interfaces 1 x RJ-45 console, 1 x USB Type-C console, 1 x out-of-band management port

Physical & Environmental
Height 1.73 inches (44 mm)
Width 17.4 inches (442 mm)
Depth 22 inches (559 mm)
Operating Temperature 0°C to 45°C (32°F to 113°F)
Storage Temperature -40°C to 70°C (-40°F to 158°F)
Operating Humidity 5% to 95% non-condensing
Acoustic Noise 68 dB maximum
Cooling Front-to-back airflow with redundant fan trays

Cloud Management & Licensing
Management Platform Aruba Central, Aruba NetEdit, WebGUI, REST API, CLI
Cloud Management Supported via Aruba Central
Software Licensing ArubaOS-CX with optional software licenses
Telemetry and Analytics Real-time monitoring with Aruba NetEdit and Aruba Central
