| Product Type | Layer 3 Managed Switch |
| Series | Aruba CX 8360 Series |
| Model | 8360-48XT4C |
| Part Number | JL706A#ACQ |
| Form Factor | 1U Rack-mountable |
| Hot-swappable Components | Yes (Fans and Power Supplies) |
| Redundant Power | Yes |
| Redundant Fans | Yes |
| AC Power Input | 100-240VAC, 50/60 Hz |
| Power Supply | Dual field-replaceable power supplies included |
| Weight | 10.8 kg (23.8 lbs) |
HP Aruba 8360-48XT4C 48-Port Switch Bundle JL706A#ACQ
Photo is for illustration purposes only. Actual product may be different.
Regular price
$32,329.03
Regular price
Sale price
$32,329.03
Unit price
per
MSRP: $40,835.00
Shipping calculated at checkout.
Couldn't load pickup availability
- - Includes a 48-port switch with dual power and fan units for redundancy
- - TAA compliant, ideal for regulated industry deployments
- - Country of manufacture: Singapore
- - Part of Aruba's high-performance 8360 Series
- - Bundle version JL706A#ACQ for integrated hardware components
Shipping & Returns
Shipping & Returns
All our products can be shipped anywhere in the Continental United States.
Key Benefits
Eye-Insights™ by Eye-In Technologies
AI-Powered Summaries from Online Customer Reviews
AI-Powered Summaries from Online Customer Reviews
Eye-Insights™ are generated by proprietary AI that analyzes real online customer reviews to highlight top pros and key product features. While we aim for accuracy, insights are provided “as-is” and individual results may vary.
- Ideal for government and enterprise environments requiring TAA compliance.
- Redundant power and fan units improve uptime and reduce risk of system failure.
- Part of the high-end Aruba 8360 Series, known for scalable network performance.
Product Overview
The HP Aruba 8360-48XT4C is a premium L2/L3 switch bundle from the Aruba 8360 Series, purpose-built for enterprise-grade networking. With dual power and fan units included, the model JL706A#ACQ enhances system resiliency and supports redundant operations. Its TAA compliance makes it suitable for regulated environments, including government and defense sectors. Manufactured in Singapore, the unit embodies high production standards. While many performance-specific details are not specified, the Aruba 8360 series generally supports advanced networking features, offering flexibility and scalability for evolving IT infrastructures.
Specifications
Product Overview
Wireless Features
| Wireless Support |
Compliance & Origin
| Country of Origin | Singapore |
| TAA Compliant | Yes |
| Safety Compliance | UL, CSA, EN, IEC 60950-1, 62368-1 |
| EMI Compliance | FCC Class A, VCCI Class A, EN 55032 Class A |
| Environmental Compliance | RoHS, WEEE |
Advanced Security Features
| Access Control | 802.1X Network Access Control |
| MACsec Encryption | Yes (on select interfaces) |
| ACL Support | Yes |
| Dynamic Segmentation | Yes |
Interfaces
| Total Ports | 52 |
| 10GBASE-T Ports | 48 x 1/10GBASE-T ports |
| QSFP28 Ports | 4 x 40/100G QSFP28 ports |
| Expansion Slots | 4 QSFP28 |
| Console Ports | 1 x RJ-45, 1 x USB-C |
| Management Ports | 1 x RJ-45 out-of-band management port |
| USB Port | 1 x USB Type-A |
| Throughput | Up to 2.16 Tbps |
| Switching Capacity | 2.16 Tbps |
| Forwarding Rate | 1,190 Mpps |
Physical & Environmental
| Dimensions (W x D x H) | 43.8 x 50.8 x 4.39 cm (17.24 x 20 x 1.73 in) |
| Operating Temperature | 0°C to 45°C (32°F to 113°F) |
| Storage Temperature | -40°C to 70°C (-40°F to 158°F) |
| Operating Humidity | 5% to 95% non-condensing |
| Acoustic Noise | 62 dB (max) |
| Cooling | Front-to-back airflow, redundant fans included |
Cloud Management & Licensing
| Management Interface | Aruba AOS-CX Network Operating System |
| Cloud Management | Supported via Aruba Central (license required) |
| Included Licensing | None; licenses sold separately |
| CLI Support | Yes |
| REST API | Yes |
| NetEdit Support | Yes (for configuration automation) |
