| Product Type | Fabric Module |
| Form Factor | Plug-in module |
| Compatibility | Aruba 8400X Series Switches |
| Switching Capacity | 7.2 Tbps (per module) |
| Total System Switching Capacity | Up to 19.2 Tbps |
| High Availability | Carrier-class availability with redundant components |
| Automation Support | ArubaOS-CX with REST APIs, Python scripting |
| Power Consumption | 2750 Watt |
| Weight | Approximately 5.44 kg (12 lbs) |
HP Aruba 8400X 7.2Tbps Fab Mod JL367A
Photo is for illustration purposes only. Actual product may be different.
Regular price
$9,694.35
Regular price
Sale price
$9,694.35
Unit price
per
MSRP: $12,245.00
Shipping calculated at checkout.
Couldn't load pickup availability
- Delivers up to 19.2 Tbps switching capacity for high-performance networking
- Supports 256 10GbE, 64 40GbE, or 48 40/100GbE ports for versatile connectivity
- ArubaOS-CX with REST APIs and Python scripting for automation and monitoring
- Compact form factor: 17.3 x 10.8 x 2.3 inches; optimized for data center density
- Power-efficient operation at 2750W for energy-conscious deployments
- TAA compliant and covered by a limited lifetime warranty
Shipping & Returns
Shipping & Returns
All our products can be shipped anywhere in the Continental United States.
Key Benefits
Eye-Insights™ by Eye-In Technologies
AI-Powered Summaries from Online Customer Reviews
AI-Powered Summaries from Online Customer Reviews
Eye-Insights™ are generated by proprietary AI that analyzes real online customer reviews to highlight top pros and key product features. While we aim for accuracy, insights are provided “as-is” and individual results may vary.
- Enables automation and programmability with ArubaOS-CX, REST APIs, and Python scripting, reducing operational complexity
- High port scalability and 19.2 Tbps capacity deliver future-ready performance for large enterprise networks
- Backed by a limited lifetime warranty and TAA compliance ensuring long-term reliability and procurement flexibility
Product Overview
The HP Aruba 8400X 7.2Tbps Fabric Module (JL367A) delivers carrier-class high availability and supports scalable, high-density switching with up to 256 10GbE or 48 100GbE ports. Designed for the Aruba 8400X platform, it empowers core enterprise networks with 19.2 Tbps switching capacity and advanced ArubaOS-CX automation via REST APIs and Python scripting. With a 2750W power draw and a compact footprint, it's ideal for high-performance, mission-critical infrastructures.
Specifications
Product Overview
Cloud Management & Licensing
| Network Management | ArubaOS-CX with built-in tools |
| Management Interface | REST API, Python, CLI, Web GUI |
| Automation Capabilities | Yes, via REST APIs and Python scripts |
| Licensing Model | Device-based, with optional cloud services |
Physical & Environmental
| Width | 17.3 Inch |
| Depth | 10.8 Inch |
| Height | 2.3 Inch |
| Operating Temperature | 0°C to 45°C (32°F to 113°F) |
| Storage Temperature | -40°C to 70°C (-40°F to 158°F) |
| Operating Humidity | 5% to 95% non-condensing |
| Cooling | Front-to-back airflow with redundant fans |
Interfaces
| Maximum 10GbE Ports | 256 x 10GbE (SFP/SFP+) |
| Maximum 40GbE Ports | 64 x 40GbE (QSFP+) |
| Maximum 100GbE Ports | 48 x 40/100GbE (QSFP28) |
| Port Flexibility | Supports port combination mix configuration |
| Interface Type | Hot-swappable high-speed fabric connection to line cards |
Advanced Security Features
| Network Segmentation | VXLAN with BGP EVPN support via ArubaOS-CX |
| Security Monitoring | Real-time analytics through Aruba Network Analytics Engine |
| Access Control | Integrated role-based access control (RBAC) |
Compliance & Origin
| Country of Origin | Singapore |
| TAA Compliance | Yes |
| Certifications | RoHS, WEEE, REACH, ENERGY STAR (as applicable with 8400 chassis) |
| Warranty | Limited lifetime warranty |
| Safety and EMC Compliances | IEC 60950-1, FCC, CE, VCCI, BSMI, ICES |
