HP Aruba 9300-32D 32-Port 400G Switch (R8Z96A)

VENDOR: HP Mfg Part#: R8Z96A UPC#: 190017562407
1 4
Photo is for illustration purposes only. Actual product may be different.
$94,445.76
$94,445.76
Sale Sold out
MSRP: $119,295.00
Shipping calculated at checkout.
  • 32 high-speed 400G ports and 2 additional 10G ports
  • 1.7GHz processor for enterprise-level performance
  • 32GB RAM via 2x16GB SODIMM modules
  • Storage: 128GB M.2 SSD, 4GB mSATA, 128MB SPI Flash
  • Management interfaces: RJ-45 serial, RJ-45 OOBM, and Micro USB
  • TAA compliant for use in regulated environments

Shipping & Returns

All our products can be shipped anywhere in the Continental United States.

View our shipping and return policy

View full details

Key Benefits

Eye-Insights
  • Supports ultra-fast connectivity with 32x 400G ports, ideal for growing data centers
  • TAA compliance ensures suitability for public sector and sensitive industry deployments
  • Advanced memory and storage options deliver high-performance networking and system reliability

Product Overview

The HP Aruba 9300-32D is a next-generation switch with 32 high-speed 400G ports and two 10G uplinks, tailored for enterprise-grade networks. It features a 1.7GHz processor, 32GB RAM via dual 16GB SODIMMs, and multi-tiered storage for operational agility. With TAA compliance and versatile management ports, including RJ-45 and Micro USB, it ensures secure and reliable deployments. The switch supports dual voltage input, with 220-240V required for full port utilization, optimizing it for scalable and power-efficient infrastructure.

Specifications

Product Overview
Product Type Data Center Switch
Form Factor 1U Rack-Mountable
Processor 1.7 GHz Quad-core ARM CPU
System Memory 32 GB (2 x 16 GB SODIMM)
Flash Storage 16 GB eMMC + 240 GB NVMe SSD
Weight 9.4 kg (20.7 lbs)
Power Input 100-240 VAC, 50/60 Hz
Power Required for Full Port Utilization 220–240 VAC
Redundant Power Supply Support Yes (Up to 2 PSUs)
Hot Swappable Fans Yes

Physical & Environmental
Dimensions (W x D x H) 44.0 x 49.6 x 4.4 cm (17.32 x 19.53 x 1.73 in)
Operating Temperature 0°C to 45°C (32°F to 113°F)
Storage Temperature -40°C to 70°C (-40°F to 158°F)
Operating Humidity 5% to 95% non-condensing
Acoustic Level 67.8 dB max
Airflow Direction Front-to-back
Mounting Type 19-inch rack mount

Cloud Management & Licensing
Management Platform Aruba Central (Cloud), CLI, Web GUI, REST API
Management Protocols SNMPv2/v3, RMON, sFlow, NetFlow, NTP
Cloud-Enabled Yes (via Aruba Central)
Licensing Options Foundation and Advanced Licenses via Aruba Central
Zero Touch Provisioning (ZTP) Yes

Interfaces
Total Ports 32 x 400G QSFP-DD, 2 x 10G SFP+
400G Port Type QSFP-DD
10G Port Type SFP+
Management Ports 1 x RJ-45, 1 x Micro-USB
Console Port RJ-45
USB Ports 1 x USB 3.0 Type-A
Data Transfer Rate Per Port 400 Gbps
Total System Throughput 25.6 Tbps
Switching Capacity 25.6 Tbps
Forwarding Rate 11.4 Bpps

Compliance & Origin
Country of Origin Taiwan
TAA Compliant Yes
Certifications FCC Class A, UL, cTUVus, CE, VCCI, ICES-003
RoHS Compliance Yes
Safety Standards EN 60950-1, IEC 62368-1

Advanced Security Features
Access Control 802.1X, MAC authentication, Web-based authentication
Policy Enforcement Firewall Yes (with Aruba Dynamic Segmentation)
Secure Management HTTPS, SSHv2
Encryption AES, SSL/TLS
Network Access Control ClearPass Policy Manager integration
Traffic Filtering Access Control Lists (ACLs)
