| Manufacturer | HP |
| Product Name | HP Aruba CX 8360 v2 L6-20 220V-NA 26-Port Switch |
| Manufacturer Part Number | JL711C#B2E |
| Product Type | Layer 3 Switch |
| Series | Aruba CX 8360 v2 Switch Series |
| Form Factor | 1U Rack-Mountable |
| Weight | 17.8 lbs |
| Power Consumption (Operational) | 325 Watt |
| Max Power Consumption | 325 Watt |
| Processor | 1.8 GHz 4-core CPU |
| System Memory | 16 GB RAM |
| Flash Memory | 32 GB |
HP Aruba CX 8360 v2 L6-20 220V-NA 26-Port Switch
Photo is for illustration purposes only. Actual product may be different.
Regular price
$22,781.15
Regular price
Sale price
$22,781.15
Unit price
per
MSRP: $28,775.00
Shipping calculated at checkout.
Couldn't load pickup availability
- 1. 24 ports of 1GbE/10GbE (SFP/SFP+), 2 ports of 40/100GbE (QSFP+/QSFP28)
- 2. 1.8 GHz 4-core 64-bit CPU with 16 GB RAM and 32 GB Flash
- 3. Supports Layer 3 Advanced routing protocols
- 4. High availability and resiliency features
- 5. Compact form factor: 1.73" x 17.4" x 16"; 17.8 lbs weight
- 6. Max power consumption: 325W; Idle: 120W
Shipping & Returns
Shipping & Returns
All our products can be shipped anywhere in the Continental United States.
Key Benefits
Eye-Insights™ by Eye-In Technologies
AI-Powered Summaries from Online Customer Reviews
AI-Powered Summaries from Online Customer Reviews
Eye-Insights™ are generated by proprietary AI that analyzes real online customer reviews to highlight top pros and key product features. While we aim for accuracy, insights are provided “as-is” and individual results may vary.
- Built-in high availability and resiliency features ensure robust uptime in enterprise deployments.
- Flexible port configuration with support for SFP/SFP+, QSFP+/QSFP28, and breakout cables allows future-proof scaling.
- Limited lifetime warranty and TAA compliance make it ideal for regulated industries and government contracts.
Product Overview
The HP Aruba CX 8360 v2 L6-20 220V-NA is a high-performance Layer 3 switch suited for data center and campus core applications. Powered by a 1.8 GHz 4-core CPU with 16 GB RAM and 32 GB flash storage, this switch delivers robust processing and resilient operation. Configured with 24 SFP/SFP+ ports and 2 QSFP+/QSFP28 uplink ports, it supports optional 1G/10G copper and breakout cables for deployment flexibility. With a 325W max power draw, compact dimensions, and enterprise-class features like high availability, the switch is optimized for dense environments. Manufactured in Singapore and TAA-compliant, it's backed by a limited lifetime warranty, making it ideal for public sector and high-availability networking needs.
Specifications
Product Overview
Physical & Environmental
| Height | 1.73 inch |
| Width | 17.4 inch |
| Depth | 16 inch |
| Operating Temperature | 0°C to 45°C (32°F to 113°F) |
| Storage Temperature | -40°C to 70°C (-40°F to 158°F) |
| Operating Humidity | 5% to 95% non-condensing |
Cloud Management & Licensing
| Management Interface | ArubaOS-CX CLI, Web UI, REST API |
| Included Software | ArubaOS-CX |
| Cloud-Based Management | Supported via Aruba Central (license required) |
| Licensing Model | Optional subscription required for advanced services |
Interfaces
| Total Number of Ports | 26 |
| Port Configuration | 24 x SFP/SFP+ (1G/10G), 2 x QSFP+/QSFP28 (40G/100G) |
| Interface Type | SFP, SFP+, QSFP+, QSFP28 |
| Data Transfer Rate | 100 Gbps |
| Supported Transceivers | 1GBASE-T SFP, 10GBASE-T SFP+ |
| Breakout Cable Support | 4x10G/25G |
| Data Link Protocol | 100 Gigabit Ethernet |
| Routing Protocol | Layer 3 Advanced |
Compliance & Origin
| Country of Origin | Singapore |
| TAA Compliance | Yes |
| Certifications | UL, CSA, VCCI, FCC Class A, CE |
| RoHS Compliance | Yes |
| Environmental Standards | ENERGY STAR® qualified (where applicable) |
Advanced Security Features
| Security Features | Access Control Lists (ACLs), DHCP snooping, Dynamic ARP protection, IP Source Guard |
| Traffic Filtering | Layer 2–4 packet filtering |
| MACsec Support | Yes, on select ports |
| Secure Boot | Yes |
| Trusted Platform Module (TPM) | Yes |
