StarTech USB Dual VGA over CAT5 KVM Extender - SV565DUTPU

VENDOR: STARTECH Mfg Part#: SV565DUTPU UPC#: 065030848237
1 5
Photo is for illustration purposes only. Actual product may be different.
$454.99
$454.99
Sale Sold out
Shipping calculated at checkout.
  • Supports video resolutions up to 1920x1200 over CAT5 cabling
  • Allows dual VGA and USB input control up to 650ft distance
  • OS independent operation—no drivers or software required
  • Wired technology for consistent performance and security
  • TAA-compliant design suitable for government use
  • Includes 3-year service and support from manufacturer

Shipping & Returns

All our products can be shipped anywhere in the Continental United States.

View our shipping and returns policy

View full details

Key Benefits

Eye-Insights
  • Enables secure, long-distance control of dual-display systems up to 650ft with no network exposure
  • Plug-and-play deployment with OS independence reduces setup time and IT overhead
  • Certified TAA-compliant, suitable for federally regulated environments

Product Overview

Operate a Dual VGA, USB-enabled PC up to 650ft away, as if it was installed locally - Access your KVM over long distances while not exposing yourself to the network security risks of IP KVMs - Make your KVM remotely accessible with a KVM Extender

Specifications

Product Overview
Device Type KVM Extender
Form Factor External
Power Requirements 12V DC, 1.5A
Power Consumption (Max) 7W
Included Accessories 1 x Local unit, 1 x Remote unit, 1 x USB Cable, 1 x Pack of foot pads, 1 x Instruction manual
Package Contents KVM local and remote units, USB A-B cable, user manual
Model SV565DUTPU
System Requirements OS independent; No software or drivers required
Service & Support Type 3 Years

Wireless Features
Wireless Capability

Compliance & Origin
TAA Compliant Yes
Country of Origin Taiwan
Certifications CE, FCC, RoHS

Advanced Security Features
Data Encryption No
Network Isolation Yes – KVM signal is transmitted over CAT5e without IP network involvement

Interfaces
Console Ports 2 x VGA, 2 x USB Type-A, 1 x 3.5mm Audio
Host Ports 2 x VGA, 2 x USB Type-A
Extension Link Interface 2 x RJ45 (CAT5e/6)
Max Distance Over CAT5 650 ft / 200 m
Max Resolution 1920 x 1200 @ 60 Hz
Audio Support Yes, 3.5mm stereo
Video Input VGA
Video Output VGA
USB Hub Yes, USB 1.1/2.0 compatible
KVM Technology Dual VGA with USB and audio

Physical & Environmental
Enclosure Color Black
Housing Material Steel
Width 3.1 Inch
Depth 6.1 Inch
Height 1.6 Inch
Unit Weight 1.8 lbs (0.82 kg)
Operating Temperature 0°C to 50°C (32°F to 122°F)
Storage Temperature -10°C to 60°C (14°F to 140°F)
Humidity 0% to 80% RH, non-condensing

Cloud Management & Licensing
Remote Management No IP-based remote management – uses direct cable connection
Software Required None
