Cisco UCSX-FI-6536 Fabric Interconnect, 36-Port QSFP28, 32GB RAM, 1U

VENDOR: CISCO Mfg Part#: UCSX-FI-6536-NEW
1 1
Photo is for illustration purposes only. Actual product may be different.
$0.02
$0.02
Sale Sold out
MSRP: $0.03
Shipping calculated at checkout.
  • 36 x 40/100-Gbps QSFP28 ports for high-bandwidth connectivity
  • Supports 32,000 MAC addresses and jumbo frames up to 9216 bytes
  • Layer 2 features including 802.1s, 802.1w, 802.1p, 802.1x, and 802.1q
  • 4-core CPU and 32GB RAM enhance performance for network management
  • Multiple management interfaces: RJ-45, RS-232 Serial, and USB
  • TAA compliant and RoHS certified; manufactured in the United States

Shipping & Returns

All our products can be shipped anywhere in the Continental United States.

View our shipping and returns policy

View full details

Key Benefits

Eye-Insights
  • High port density with 36 QSFP28 interfaces supports bandwidth-demanding environments
  • Advanced Layer 2 protocol support enhances security, QoS, and VLAN configurations
  • TAA compliance and U.S. manufacturing align with government procurement standards

Product Overview

The Cisco UCS Fabric Interconnect 6536 (UCSX-FI-6536) is a high-density networking solution designed for data-intensive enterprise and cloud computing environments. This 1U unit features 36 ports of 40/100-Gbps QSFP28 connectivity, enabling high-throughput data transfer capabilities. Supporting up to 32,000 MAC addresses and jumbo frames up to 9216 bytes, it excels in demanding network tasks such as virtualization and big data workloads.

Equipped with a 4-core CPU and 32GB of RAM, and supporting advanced Layer 2 protocols like IEEE 802.1s/w/p/q/x, the UCSX-FI-6536 ensures optimal performance and segmentation efficiency. Management is facilitated through RJ-45, RS-232 Serial, and USB interfaces. Note: Power supply is not included, supporting customizable deployment scenarios.

TAA compliant and manufactured in the USA, this unit meets the needs of institutional buyers while aligning with environmental standards through RoHS certification. It’s an ideal choice for scalable enterprise networking.

Specifications

Product Overview
Product Type Fabric Interconnect
Model UCSX-FI-6536
Form Factor 1U Rackmount
Processor 4-core CPU
System Memory 32 GB RAM
Switch Capacity 7.2 Tbps throughput
Forwarding Rate 2.8 billion packets per second (bpps)
MAC Address Table Size 32,000 MAC addresses
Jumbo Frame Support 9216 bytes
Power Supply Included No (ordered separately)

Wireless Features
Wi-Fi Support

Compliance & Origin
Country of Origin United States
TAA Compliant Yes
RoHS Compliant Yes
Certifications FCC, UL, CE, VCCI, IEC/EN 60950-1

Advanced Security Features
802.1x Authentication Supported
Access Control Lists (ACLs) Supported
Storm Control Supported
Port Security Yes
Role-Based Access Control Yes
SNMPv3 Support Yes

Interfaces
Number of Ports 36
Port Type QSFP28
Port Speed 40/100 Gbps
Management Ports 1 x RJ-45 Ethernet, 1 x RS-232 Serial, 1 x USB
Aggregate Bandwidth 7.2 Tbps

Physical & Environmental
Height 1.72 in (43.6 mm)
Width 16.9 in (430 mm)
Depth 30.35 in (771 mm)
Weight 32.63 lb (14.8 kg)
Operating Temperature Range 32°F to 104°F (0°C to 40°C)
Storage Temperature Range -40°F to 158°F (-40°C to 70°C)
Operating Humidity 5% to 95% (non-condensing)
Non-operating Humidity 5% to 93% (non-condensing)
Airflow Front to rear or rear to front (dependent on configuration)

Cloud Management & Licensing
Management Interface Cisco UCS Manager
Cloud Managed Supported via Cisco Intersight
Licensing Model Cisco Smart Licensing
Software Included Cisco UCS Software (UCSM)
Remote Management Yes
