| Type | Outdoor LED Display |
| Model | LH080XHBCIE |
| Form Factor | Flat |
| Power Consumption (Operational) | 100 Watt |
| Power Requirements | 100-240 VAC, 50/60 Hz |
| Weight | 15.9 kg |
Samsung XHB-EP8FLAT1X3 Outdoor LED Display, LH080XHBCIE
Photo is for illustration purposes only. Actual product may be different.
Regular price
$1,307.88
Regular price
Sale price
$1,307.88
Unit price
per
MSRP: $1,746.34
Shipping calculated at checkout.
Couldn't load pickup availability
- LED display with flat design and outdoor durability
- Extremely high brightness of 7000 nits for daylight visibility
- 281 trillion color support for high-fidelity visuals
- 7680 Hz refresh rate for smooth motion rendering
- Operates in wide temperature range from -40°C to 50°C
- Power-efficient at 100 watts with voltage support from 100–240 VAC
Shipping & Returns
Shipping & Returns
All our products can be shipped anywhere in the Continental United States.
Key Benefits
Eye-Insights™ by Eye-In Technologies
AI-Powered Summaries from Online Customer Reviews
AI-Powered Summaries from Online Customer Reviews
Eye-Insights™ are generated by proprietary AI that analyzes real online customer reviews to highlight top pros and key product features. While we aim for accuracy, insights are provided “as-is” and individual results may vary.
- Optimized for professional outdoor installations requiring extreme brightness and high contrast performance
- Engineered to endure harsh environments with wide temperature tolerance and TAA compliance
- Delivers impressive ROI through power efficiency and minimal maintenance requirements due to robust build
Product Overview
The Samsung XHB-EP8FLAT1X3 (Model LH080XHBCIE) is a flat-format outdoor LED display crafted for resilience and high-visibility performance. With a brightness level of 7000 nits, 7000:1 contrast ratio, and support for 281 trillion colors, it ensures brilliant and lifelike visuals even under direct sunlight. A pixel pitch of 8.21 mm and 7680 Hz refresh rate make it ideal for high-detail and motion-intensive content. Designed to operate in extreme conditions from -40°C to 50°C, the display is TAA compliant and power efficient at just 100W. Its versatile viewing angles (160° H / 117° V) and manageable physical dimensions support a wide range of outdoor signage applications.
Specifications
Product Overview
Wireless Features
| Wireless Connectivity |
Physical & Environmental
| Width | 344.6 mm |
| Height | 1035.4 mm |
| Depth | 92 mm |
| Operating Temperature (Min) | -40°C |
| Operating Temperature (Max) | 50°C |
| Humidity Tolerance | 10%~90% (non-condensing, estimated) |
| Ingress Protection Rating | IP66 (Front), IP66 (Rear) |
Cloud Management & Licensing
| Management Platform | Samsung MagicINFO (Optional) |
| Included Software | |
| Remote Monitoring Support | Yes (via MagicINFO or SNMP) |
| Licensing Required | MagicINFO License (Sold Separately) |
Interfaces
| Input Interface | Proprietary LED Signage Interface (Exact port configuration not publicly listed) |
| Control Interface | RJ45 / RS232C (via Controller) |
| Video Processing | External Controller Required (e.g., Samsung XCL Series) |
Display Features
| Brightness | 7000 nits |
| Contrast Ratio | 7000:1 |
| Color Support | 281 Trillion Colors |
| Pixel Pitch | 8.21 mm |
| Refresh Rate | 7680 Hz |
| Max Resolution | 42 x 126 pixels per cabinet |
| Viewing Angle (Horizontal / Vertical) | 160° / 117° |
| HDR Support | None |
| Response Time |
Compliance & Origin
| TAA Compliant | Yes |
| Country of Origin | Mexico |
| Certifications | EMC Class A, CE, FCC, UL60950-1 / IEC60950-1 |
Advanced Security Features
| Content Protection | Encryption Support via MagicINFO |
| Network Security Support | HTTPS, SNMPv3 (via Controller) |
| Tamper Resistance | Lockable installation supported |
