| Product Type | Network Management Appliance |
| Model | NVIDIA UFM Appliance 3.0 |
| Form Factor | 1U Rackmount |
| Processor | Dual Intel Xeon Silver processors (exact model may vary) |
| Memory | 256 GB DDR4 ECC Registered |
| Storage | 2x 960GB NVMe SSD (RAID 1) |
| Included Software | UFM Telemetry or UFM Enterprise pre-installed |
| Power Supply | Dual redundant hot-swappable 1200W PSU |
| Power Requirements | 100-240 VAC, 50-60Hz |
| Weight | 17 kg (approximate) |
NVIDIA UFM Appliance 3.0, 1U Server with 2x ConnectX-7 400Gb/s IB
Photo is for illustration purposes only. Actual product may be different.
Regular price
$23,832.58
Regular price
Sale price
$23,832.58
Unit price
per
MSRP: $30,600.00
Shipping calculated at checkout.
Couldn't load pickup availability
- 1U server with high-density design
- Pre-installed UFM software (license required separately)
- 2x ConnectX-7 NDR single-port 400Gb/s InfiniBand adapters
- Secured-boot supported for increased system integrity
- TAA compliant and manufactured in Israel
Shipping & Returns
Shipping & Returns
All our products can be shipped anywhere in the Continental United States.
Key Benefits
Eye-Insights™ by Eye-In Technologies
AI-Powered Summaries from Online Customer Reviews
AI-Powered Summaries from Online Customer Reviews
Eye-Insights™ are generated by proprietary AI that analyzes real online customer reviews to highlight top pros and key product features. While we aim for accuracy, insights are provided “as-is” and individual results may vary.
- Designed for high-throughput AI and HPC workloads with 2x 400Gb/s InfiniBand ports.
- Secure and compliant infrastructure with secured-boot features and TAA compliance.
- Comes with UFM software pre-installed, reducing deployment complexity.
Product Overview
The NVIDIA UFM Appliance 3.0 is an advanced 1U network-management server tailored for UFM Telemetry or UFM Enterprise deployments. It includes 2x ConnectX-7 NDR 400Gb/s InfiniBand ports to support high-bandwidth environments. Featuring secured-boot and TAA compliance, the appliance is suitable for use in security-conscious and federally regulated sectors. Designed for real-time network visibility and proactive system control, the server improves operational efficiency across HPC and AI data centers. The UFM software is pre-installed; license is required separately.
Specifications
Product Overview
Physical & Environmental
| Dimensions (W x D x H) | 438 mm x 700 mm x 43 mm |
| Rack Units | 1U |
| Operating Temperature | 10°C to 35°C (50°F to 95°F) |
| Non-Operating Temperature | -40°C to 70°C (-40°F to 158°F) |
| Operating Humidity | 8% to 90% non-condensing |
| Non-Operating Humidity | 5% to 95% non-condensing |
| Cooling | Redundant hot-swappable fans |
| Noise Level | Under 55 dBA at typical operation |
Cloud Management & Licensing
| Management Software | UFM Telemetry/UFM Enterprise (license required separately) |
| Cloud Management Interface | Web-based GUI, REST API, CLI |
| Remote Management | Integrated BMC with IPMI 2.0 support |
| Telemetry Features | Real-time traffic insights, system health monitoring |
Interfaces
| InfiniBand Ports | 2 x 400Gb/s NDR InfiniBand single-port with ConnectX-7 |
| InfiniBand Interface Type | NVIDIA ConnectX-7 |
| InfiniBand Speed | 400 Gb/s per port |
| Network Ports | 2 x 10GbE RJ-45; 2 x 1GbE RJ-45 management ports |
| USB Ports | 2 x USB 3.0 |
| Video Output | 1 x VGA |
| Serial Port | 1 x RS232 |
| IPMI Port | 1 x dedicated RJ-45 for out-of-band management |
Compliance & Origin
| TAA Compliance | Yes |
| Country of Origin | Israel |
| RoHS Compliance | Yes |
| Certifications | CE, FCC, UL, VCCI, CB, BSMI |
Advanced Security Features
| Secure Boot | Yes |
| Firmware Protection | Signed firmware with verification |
| System Authentication | Role-Based Access Control (RBAC) |
| Audit Logging | Yes |
| Trusted Platform Module (TPM) | TPM 2.0 |
