HP Aruba 8360-24XF2C 24-Port 10GbE Switch Bundle JL710A#AKJ

VENDOR: HP Mfg Part#: JL710A#AKJ UPC#: 190017406145
1 3
Photo is for illustration purposes only. Actual product may be different.
$25,061.24
$25,061.24
Sale Sold out
MSRP: $31,655.00
Shipping calculated at checkout.
  • 26 wired 10Gbps Ethernet ports for high-speed data transfer
  • System memory: 16GB for operational efficiency
  • Storage capacity: 32GB for configuration and logs
  • TAA-compliant, suitable for government procurement
  • Manufactured in Singapore, ensuring quality and compliance

Shipping & Returns

All our products can be shipped anywhere in the Continental United States.

View our shipping and returns policy

View full details

Key Benefits

Eye-Insights
  • Supports high-throughput networks with 26-port 10GbE design, ideal for data centers and campus cores
  • TAA compliance ensures eligibility for government and public sector contracts
  • Includes large onboard memory and storage for complex networking configurations and scalability

Product Overview

The HP Aruba 8360-24XF2C Prt2Pwr3F2PS Bdl IL en is a high-capacity 10 Gigabit Ethernet switch ideal for enterprise environments. It offers 26 wired ports to support large-scale deployments and integrates 16GB of memory with 32GB storage for advanced configurations. TAA-compliant and manufactured in Singapore, this bundle meets both performance and regulatory standards, making it a strong fit for commercial and government network infrastructure.

Specifications

Product Overview
Product Type Managed Ethernet Switch
Form Factor 1U Rack-mountable
Switch Series Aruba CX 8360 Series
Model Number 8360-24XF2C
Bundle Part Number JL710A#AKJ
Total Ports 26
Memory 16 GB
Storage Capacity 32 GB eMMC
Power Supply Type Dual hot-swappable power supplies included
Power Consumption Up to 180W
Redundant Power Support Yes
AC Voltage Input Range 100–240V AC

Physical & Environmental
Dimensions (W x D x H) 43.9 x 48 x 4.39 cm (17.3 x 18.9 x 1.73 in)
Weight 9.5 kg (20.9 lbs)
Operating Temperature Range 0°C to 45°C (32°F to 113°F)
Storage Temperature Range -40°C to 70°C (-40°F to 158°F)
Operating Humidity Range 5% to 95% (non-condensing)
Acoustic Noise ≤ 63 dB
Cooling Front-to-back airflow with redundant fans

Cloud Management & Licensing
Management Platform Aruba Central (cloud), Aruba NetEdit, CLI, Web GUI, REST API
Switch OS ArubaOS-CX
Cloud-Ready Yes
Licensing Requirement Advanced features require Aruba Central subscription

Interfaces
10G SFP+ Ports 24
40G QSFP+ Ports 2
Total Uplinks 2 x 40G QSFP+
Console Port 1 x RJ-45 & 1 x Micro-USB
Management Ports 1 x RJ-45 10/100/1000 Mbps
USB Port 1 x USB Type-A
Architecture Fully distributed
Switching Capacity 1.28 Tbps
Forwarding Rate 952.32 Mpps

Compliance & Origin
Country of Origin Singapore
TAA Compliant Yes
Certifications UL, EN 60950, FCC Class A, CE, VCCI, BSMI, CCC, EAC
RoHS Compliance Yes

Advanced Security Features
Access Control MACsec 256-bit encryption, 802.1X, MAC authentication, captive portal
Traffic Protection Dynamic segmentation with integrated policy enforcement
Security Protocols SSL, SSH, RADIUS, TACACS+, SNMPv3
