Cisco Atlas IHVP Outdoor Vandal Resistant IP Speaker

VENDOR: CISCO Mfg Part#: SP-ATLAS-IHVP=
  • The Cisco Atlas IHVP Outdoor Speaker offers vandal-resistant IP audio solutions with a rugged stainless steel build and flush-mount design. Ideal for high-security or outdoor environments, it features a 15W driver, 8 Ohm impedance, and IEEE 802.3af PoE compatibility. Its high-efficiency construction ensures reliable voice and tone signal delivery in harsh operating conditions.
1 1
Photo is for illustration purposes only. Actual product may be different.
$1,378.00
$1,378.00
Sale Sold out
MSRP: $2,003.00
Shipping calculated at checkout.
  • Stainless steel flush-mount construction for vandal resistance
  • 15W RMS compression driver with 120 dB sensitivity
  • Operates on IEEE 802.3af PoE or 12–18VDC power
  • Wide 600 Hz to 14 kHz frequency response range
  • RJ-45 connector for streamlined IP audio integration
  • TAA-compliant and made in the United States
View full details

Key Benefits

Eye-Insights
  • Engineered for harsh outdoor and high-security environments with a rugged stainless steel design
  • Reliable audio delivery with a high-efficiency 15W speaker and double re-entrant horn for voice/tone clarity
  • Supports modern networked deployments with PoE power and RJ-45 IP connectivity

Product Overview

The Cisco Atlas IHVP is a vandal-resistant IP speaker designed for rugged outdoor deployments. With a stainless steel flush-mount baffle and a 15W high-sensitivity compression driver, it delivers superior voice and tone signaling for security and industrial applications. Key features include PoE power via IEEE 802.3af, RJ-45 connectivity, and frequency response from 600 Hz to 14 kHz. Built in the United States and TAA compliant, it provides a secure and efficient communication solution for critical infrastructures.

Specifications

Primary Information
Manufacturer Cisco Systems, Inc
RMS Output Power 15
Maximum Frequency Response 14
Minimum Frequency Response 600
Depth 4.88" (123.83 mm)
Width 10.8"
Height 10.8"
Brand Name Cisco
Product Name Atlas Sound IHVP Speaker
Product Model IHVP
Material Stainless Steel
Form Factor Flush Mount
Driver Type 5.63" (142.88 mm)
Color White
Sensitivity 120
Marketing Information

Model IHVP from Atlas Sound consists of a factory assembled horn loudspeaker/baffle with PCB amp/control board securely mounted to the rear of the baffle via concealed weld studs.

The amp/control board is capable of producing 9 Watts RMS into the 8 Ohm loudspeaker with 9VDC minimum power provided by IEEE 802.3 AF compliant POE switches (local 12-18VDC PSU's may also be used instead of POE switches). Interconnection is via a board mounted female RJ-45 connector.

The industry standard APF-15 loudspeaker used in the IHVP is a highly efficient 15 Watt compression driver with a proven record of outstanding service reliability. A double re-entrant design provides superior audibility of voice and tone signaling.
Manufacturer Website Address http://www.cisco.com
Manufacturer Part Number SP-ATLAS-IHVP=
Impedance 8
Product Type Speaker
Service & Support Type
Service Included
Response Time
Full Contract Period
Features
Cable Type
Left Connector Type
Right Connector Type
Brand
Length
Device Type
Cabling Type
Data Transfer Rate
Wave Length
Max Transfer Distance
Interfaces

UNSPSC Code
UNSPSC Code 52161512

Dimensions&Miscellaneous
Width
Depth
Height

Special Feature
COO UNITED STATES
TAA compliance Yes
