LG LSBF015 DVLED Display, P1.56, 768x432, 600 Nit, TAA Compliant

VENDOR: LG Mfg Part#: LSBF015-GDC UPC#: 195174076231
  • LSBE, DVLED, P1.56, 768X432 RESOLUTION, WITH L/R CUT 45 DEGREE MITER, ESSENTIAL 1 CLASS, TAA SERIES, SINGLE SMD, 600 NIT, 1200X675X72
  • LSBE, DVLED, P1.56, 768X432 RESOLUTION, WITH L/R CUT 45 DEGREE MITER, ESSENTIAL 1 CLASS, TAA SERIES, SINGLE SMD, 600 NIT, 1200X675X72
  • LSBE, DVLED, P1.56, 768X432 RESOLUTION, WITH L/R CUT 45 DEGREE MITER, ESSENTIAL 1 CLASS, TAA SERIES, SINGLE SMD, 600 NIT, 1200X675X72
  • LSBE, DVLED, P1.56, 768X432 RESOLUTION, WITH L/R CUT 45 DEGREE MITER, ESSENTIAL 1 CLASS, TAA SERIES, SINGLE SMD, 600 NIT, 1200X675X72
1 4
Photo is for illustration purposes only. Actual product may be different.
$8,435.00
$8,435.00
Sale Sold out
MSRP: $10,544.00
Shipping calculated at checkout.
  • 1.56mm pixel pitch for detailed imagery at close viewing distances
  • 768 x 432 resolution delivering crisp visuals
  • 600 nit brightness (after calibration) with 5000:1 contrast ratio
  • Flat configuration with 45-degree miter edge for seamless video wall designs
  • Operates from -20°C to 40°C and 10–80% relative humidity
  • TAA compliant and made in Slovakia
View full details

Key Benefits

Eye-Insights
  • Ideal for high-resolution video wall installations due to its fine 1.56mm pixel pitch and seamless corner compatibility
  • TAA compliance ensures it meets federal institutional procurement requirements
  • Robust temperature and humidity tolerance enhances long-term operational reliability in varied indoor environments

Product Overview

LSBE, DVLED, P1.56, 768X432 RESOLUTION, WITH L/R CUT 45 DEGREE MITER, ESSENTIAL 1 CLASS, TAA SERIES, SINGLE SMD, 600 NIT, 1200X675X72

Specifications

Primary Information
Model LSBF015
Display Type LED Backlight
Flat / Curved Flat
Display / Refresh Rate 3840 Hz
Dot Pitch / Pixel Pitch 1.56 Mm
Image Contrast Ratio 5000:1
Brightness Max. Brightness (After Calibration) 600
Power Consumption Operational Power Consumption (W/Cabinet, Max.) 428 Power Consumption (W/Cabinet, Avg.) 182 Power Consumption (W/m, Max.) 530 Watt
Power / Voltage Required 100 to 240
Width 1200 Mm
Depth 675 Mm
Height 72 Mm
Weight 23 Kg
Min Operating Temperature -20C
Max Operating Temperature 40C
Humidity Range Operating 10-80% RH

Power
Power / Voltage Required 100 to 240
Power Consumption Operational Power Consumption (W/Cabinet, Max.) 428 Power Consumption (W/Cabinet, Avg.) 182 Power Consumption (W/m, Max.) 530 Watt

UNSPSC Code
UNSPSC Code 44111511

Display
Brightness Max. Brightness (After Calibration) 600
Display Type LED Backlight
Dot Pitch / Pixel Pitch 1.56 Mm
Flat / Curved Flat
Flat / Curved Flat

Special Feature
COO SLOVAKIA
TAA compliance Yes
